Delivery time depends on order quantity.

Our company other related product:

1.Deep groove ball bearing--	60,62,63,64,67,68,69,160 series
2.Angular contact ball bearing--	single row, double row,high precision
3.Self-aligning ball bearing--	12,13,14,22,23 series
4.Thrust ball bearing--	511,512,513,514 series
5.Spherical roller bearing--	213,223,222,223,230,240,231series
6.Cylindrical roller bearing--	N,NH,NF,NJ,NUH,EG,NN,NNU series
7.Taper roller bearing--	30,31,32,33,LM,HM series
8.Needle roller bearing--	K,K-TN,K-ZW series
9.Linear guide rail block bearing--	LR,SHS,SSR,SHW,SRS,HSR HRW series
10.Linear bush bearing--	LM,LME,LMF,LMK,LMH,SC,SL,SK series
11.Eccentric bearing--	15UZ,22UZ,25UZ,60UZ,65UZ,607,610 series
12.Adapter sleeve--	H,AH series
13.Slewing bearing--	01,02,11,13 series

Product Features:

1. able to carry high loads

2. with high precision bearing steel,chorm steel,carbon steel

3. with a high load-bearing capacity

4. more quietly than metal roller bearings

5. low noise, stable performance and durable

6. able to work in sub-zero temperatures and have low rolling resistance

7. suitable for countless applications: sliding doors, windows and other furnitures

hollow glass production line, construction and engineering design, spurt the code machine, spices processing equipment, heat exchanger, water treatment equipment, variable frequency pump, electric welding machine, household sewing machine,

workbench, sorting sieve, plating equipment, polishing machine, rubber machine, pelletizing machine, plastic calender, farm machinery fittings, granulating drying equipment, etc

Specification:

Flanged housings, FNL series

FNL flanged housings are well-proven machine parts that provide simple, reliable housing in applications without horizontal frames. They enable the full service life potential of the incorporated bearings to be exploited with less need for maintenance.

Bearing types

Self-aligning ball bearings
Spherical roller bearings
CARB toroidal roller bearings

Bearing dimension series

02, 22

Shaft diameter range

20 to 100 mm

Typical shaft-bearing combinations

Plain shaft with bearing on an adapter sleeve

Seals

Double-lip

Lubrication

Grease

Materials

Grey cast iron

Mounting

Three-bolt mounting
Four-bolt mounting

Compliance to standards

Not standardized

Supersedes

7225(00)

Application

workbench, sorting sieve, plating equipment, polishing machine, rubber machine, pelletizing machine, plastic calender, farm machinery fittings, granulating drying equipment, etc

Housing	Shaft dia	Dimensions(mm)													Housing	Bearing	Adapter	Locating Ring		Housing
No.	d₁	D	g	h	w	L	(L₁)	a	b	c	e	e	n	S	Wt (kg)	No.	Sleeve			No.
	(in)	H8	H12	h12							max	min						Number	QTY
SAF609	2001-7-16	100	46	69.9	135	105	108	245	70	25	200.2	187.5		M16	7.2	1309K	HA309	FR100x10.5	2	SAF609
														-2		2309K	HA2309	FR100x10	1
																21309K	HA309	FR100x10.5	2
																22309K	HA2309	FR100x10	1
SAF610	2001-11-16	110	51	76.2	148	114	118	270	70	29	228.6	196.9		M16	9.2	1310K	HA310	FR110x11.5	2	SAF610
														-2		2310K	HA2310	FR110x10	1
																21310K	HA310	FR110x11.5	2
																22310K	HA2310	FR110x10	1
SAF611	1-15/16	120	53	82.6	157	121	124	279	80	30	241.3	206.5		M16	11	1311K	HA311	FR120x12	2	SAF611
														-2		2311K	HA2311	FR120x10	1
																21311K	HA311	FR120x12	2
																22311K	HA2311	FR120x10	1
FSAF611	1-15/16	120	53	82.6	157	121	124	279	80	30	241.3	206.5	51	M12	11	1311K	HA311	FR120x12	2	FSAF611
														-4		2311K	HA2311	FR120x10	1
																21311K	HA311	FR120x12	2
																22311K	HA2311	FR120x10	1
SAF613	2002-3-16	140	58	88.9	176	133	137	330	90	32	279.4	244.6		M20	13.3	1313K	HA313	FR140x12.5	2	SFA613
														-2		2313K	HA2313	FR140x10	1
																21313K	HA313	FR140x12.5	2
																22313K	HA2313	FR140x10	1
FSAF613	2002-3-16	140	58	88.9	176	133	137	330	90	32	279.4	244.6	54	M16	13.3	1313K	HA313	FR140x12.5	2	FSAF613
														-4		2313K	HA2313	FR140x10	1
																21313K	HA313	FR140x12.5	2
																22313K	HA2313	FR140x10	1
SAF615	2002-7-16	160	65	101.6	197	149	159	349	100	33	295.4	263.7		M20	21	1315K	HA315	FR160x14	2	SAF615
														-2		2315K	HA2315	FR160x10	1
																21315K	HA315	FR160x14	2
																22315K	HA2315	FR160x10	1
FSAF615	2002-7-16	160	65	101.6	197	149	159	349	100	33	295.4	263.7	54	M16	21	1315K	HA315	FR160x14	2	FSAF615
														-4		2315K	HA2315	FR160x10	1
																21315K	HA315	FR160x14	2
																22315K	HA2315	FR160x10	1
SAF616	2002-11-16	170	68	108	210	156	165	362	100	33	320.8	270		M20	24	1316K	HA316	FR170x14.5	2	SAF616
														-2		2316K	HA2316	FR170x10	1
																21316K	HA316	FR170x14.5	2
																22316K	HA2316	FR170x10	1
FSAF616	2002-11-16	170	68	108	210	156	165	362	100	33	320.8	270	54	M16	24	1316K	HA316	FR170x14.5	2	FSAF616
														-4		2316K	HA2316	FR170x10	1
																21316K	HA316	FR170x14.5	2
																22316K	HA2316	FR170x10	1
SAF617	2-15/16	180	70	114.3	222	165	172	387	111	45	333.5	295.4		M24	27	1317K	HA317	FR180x14.5	2	SAF617
														-2		2317K	HA2317	FR180x10	1
																21317K	HA317	FR180x14.5	1
																22317K	HA2317	FR180x10	1
FSAF617	2-15/16	180	70	114.3	222	165	172	387	111	45	333.5	295.4	61	M20	27	1317K	HA317	FR180x14.5	2	FSAF617
														-4		2317K	HA2317	FR180x10	1
																21317K	HA317	FR180x14.5	1
																22317K	HA2317	FR180x10	1
SAF618	2003-3-16	190	74	120.7	233	168	175	394	111	51	342.9	304.8	57	M20	29.5	1318K	HA318	FR190x11.5	2	SAF618
														-4		2318K	HA2318	FR190x10	1
																21318K	HA318	FR190x15.5	2
																20318K	HA318	FR190x15.5	2
																22318K	HA2318	FR190x10	1
SAF620	2003-7-16	215	83	133.3	260	181	187	419	121	54	368.3	336.6	70	M20	42	1320K	HA320	FR215x18	2	SAF620
														-4		2320K	HA2320	FR215x10	1
																20320K	HA320	FR215x18	2
																21320K	HA320	FR215x18	2
																22320K	HA2320	FR215x10	1
SAF622	3-15/16	240	90	152.4	292	197	203	467	130	61	406.4	371.6	83	M20	50	1322K	HA322	FR240x20	2	SAF622
														-4		20322K	HA322	FR240x20	2
																21322K	HA322	FR240x20	2
																22322K	HA2322	FR240x10	1
SAF624	2004-3-16	260	96	160.4	318	207	213	540	160	64	463.6	431.8	95	M24	72	20324K	HA3124	FR260x20.5	2	SAF624
														-4		22324K	HA2324	FR260x10	1
SAF626	2004-7-16	280	103	169.9	338	216	222	559	160	67	489	441.5	95	M24	77.7	20326K	HA3126	FR280x22.5	2	SAF626
														-4		22326K	HA2326	FR280x10	1
SAF628	4-15/16	300	112	179.4	360	235	238	629	172	70	549.4	492.3	108	M24	95	20328K	HA3128	FR300x25	2	SAF628
														-4		22328K	HA2328	FR300x10	1
SAF630	2005-3-16	320	118	190.5	378	245	248	680	181	76	600.2	530.4	117.6	M24	118	20330K	HA3130	FR320x26.5	2	SAF630
														-4		22330K	HA2330	FR320x10	1
SAF632	2005-7-16	340	124	200	398	267	270	711	191	80	619.3	549.4	114.3	M30	128	20332K	HA3132	FR340x28	2	SAF632
														-4		22332K	HA2332	FR340x10	1
SAF634	5-15/16	360	130	209.6	419	279	286	749	203	86	635	571.5	127	M30	150	22334K	HA2334	FR360x10	1	SAF634
														-4
SAF636	2006-7-16	380	136	225.4	451	282	289	794	210	89	676	610	133	M30	170.2	22336K	HA2336	FR380x10	1	SAF636
														-4
SAF638	6-15/16	400	142	241.3	473	298	305	832	222	95	708.2	628.7	133.4	M30	198	22338K	HA2338	FR400x10	1	SAF638
														-4
SAF640	2007-3-16	420	148	250.8	508	299	306	870	229	102	749	667	140	M30	255	22340K	HA2340	FR420x10	1	SAF640
														-4

Packaging & Shipping

Packaging

Shipping

FAQ

1.What is the MOQ of your company?

Our company MOQ is 1pcs.

2.Could you accept OEM and customize?
YES, we can customize for you according to sample or drawing.

3.Could you supply sample for free?
Yes, we can supply sample for free, but need our customer afford freight.

4.Does your factory have CE?
Yes, we have ISO 9001:2008, and SASO. If you want other CE, we can do for you.

5.Does your company factory or Trade Company?

We have our own factory; our type is factory + trade.

6.What is the guarantee of your bearing quality period:?
1year! Customer need supply photos and send bearing back.
