Standard YAR 213-208-2F Y-bearings with grub screws are manufactured from high-grade carbon chromium steel.Y-bearings in the YAR 2 series have an extended inner ring on both sides This reduces the extent to which the inner ring can tilt on the shaft, which enables the bearing to run more smoothly.
Technical data of YAR 213-208-2F
ID: 63.5 mm
OD: 120 mm
Width: 68.3 mm
Weight: 1.70 kg
Basic dynamic load rating: 57.2 kN
Basic static load rating: 40 kN
Fatigue limit load: 1.86 kN
Limiting speed: 2800 rpm
Part YAR 2-2F series Y-bearings catalogue
Y bearing designation |
d mm |
D mm |
B mm |
C mm |
mass kg |
YAR 212-204-2F |
57,15 |
110 |
65,1 |
26 |
1,45 |
YAR 212-204-2F/AH |
57,15 |
110 |
65,1 |
26 |
1,45 |
YAR 212-2F |
60 |
110 |
65,1 |
26 |
1,30 |
YAR 212-2RF |
60 |
110 |
65,1 |
26 |
1,30 |
YAT 212-207 |
61,913 |
110 |
48,5 |
26 |
1,10 |
YAR 212-207-2F |
61,913 |
110 |
65,1 |
26 |
1,30 |
YAR 212-207-2F/AH |
61,913 |
110 |
65,1 |
26 |
1,30 |
YAR 214-207-2F |
61,913 |
125 |
69,9 |
28 |
2,40 |
YAR 214-207-2F/AH |
61,913 |
125 |
69,9 |
28 |
2,40 |
YAR 213-208-2F |
63,5 |
120 |
68,3 |
27 |
1,70 |
YAR 213-208-2F/AH |
63,5 |
120 |
68,3 |
27 |
1,70 |
YAR 213-208-2RF |
63,5 |
120 |
68,3 |
27 |
1,70 |
YAR 214-208-2F |
63,5 |
125 |
69,9 |
28 |
2,15 |
YAR 214-208-2F/AH |
63,5 |
125 |
69,9 |
28 |
2,15 |
YAR 213-2F |
65 |
120 |
68,3 |
27 |
1,70 |
YAR 213-2RF |
65 |
120 |
68,3 |
27 |
1,70 |
YAR 213-211-2F |
68,263 |
120 |
68,3 |
27 |
1,50 |
YAR 213-211-2F/AH |
68,263 |
120 |
68,3 |
27 |
1,50 |
YAR 215-211-2F |
68,263 |
130 |
73,1 |
29 |
2,50 |
YAR 215-211-2F/AH |
68,263 |
130 |
73,1 |
29 |
2,50 |
YAR 215-212-2F |
69,85 |
130 |
73,1 |
29 |
2,40 |
YAR 215-212-2F/AH |
69,85 |
130 |
73,1 |
29 |
2,40 |
YAR 214-2F |
70 |
125 |
69,9 |
28 |
1,90 |
YAT 215-215 |
74,612 |
130 |
53,5 |
29 |
1,75 |
YAR 215-215-2F |
74,612 |
130 |
73,1 |
29 |
2,10 |
YAR 215-215-2F/AH |
74,612 |
130 |
73,1 |
29 |
2,10 |
YAR 216-215-2F |
74,612 |
140 |
77,9 |
30 |
2,95 |
YAR 216-215-2F/AH |
74,612 |
140 |
77,9 |
30 |
2,95 |
YAR 215-2F |
75 |
130 |
73,1 |
29 |
2,10 |
YAT 216-300 |
76,2 |
140 |
55,5 |
30 |
2,35 |
YAR 216-300-2F |
76,2 |
140 |
77,9 |
30 |
2,85 |
YAR 216-300-2F/AH |
76,2 |
140 |
77,9 |
30 |
2,85 |
YAR 216-2F |
80 |
140 |
77,9 |
30 |
2,80 |
YAR 217-2F |
85 |
150 |
81 |
34 |
3,30 |
YAR 218-2F |
90 |
160 |
89 |
36 |
4,10 |
YAR 220-2F |
100 |
180 |
98,4 |
40 |
5,65 |
YAR 213-208-2F Y-bearings have plain sheet steel flingers and can be re-lubricated through two lubrication holes outer ring. If you have any special requirement for your application, please contact our sales engineers.
