Thrust ball bearing 51101
Description of bearing 51101:
Product name |
Roller Bearing 51101 |
Brand name |
KMY/OEM |
Original Packing |
(a)Neutral package & wooden package |
Precision |
P2/P4/P5/P6/P0 |
Material |
GCR-15 chrom steel,Bearing Steel |
Quality standard |
ISO9001:2000 |
Delivery date |
Within 5 working days or according to you request |
Payment terms |
A:100% T/T in advance at sight B:30%T/T in advance.70% against copy of B/L |
Features |
these bearings are featured by the extremely big axial load carrying capacity and meanwhile,they can also carry cetain radial load |
Package |
sigle box/industrial standard packing/single carton/according to buyers requirement |
Cage Material |
Bearing steel/brass |
Main market |
Mideast;Canda;Southeast Asia;South America and other countries all over the world |
Company name |
Jinan Kaiming Bearing CO.,LTD |
Contact |
Helen Gao Skype:qgbearing2013 Tel:0086-0531-85066228 Fax:0086-0531-85066708 Alibaba:jinankm |
2.bearing list:
| Bearing | ID | OD | B | Cr | Cor | Weight |
| (mm) | (mm) | (mm) | (kN) | (kN) | (kg) | |
| 51100 | 10 | 24 | 9 | 10 | 14 | 0.02 |
| 51101 | 12 | 26 | 9 | 10.3 | 15.4 | 0.022 |
| 51102 | 15 | 28 | 9 | 10.5 | 16.8 | 0.024 |
| 51103 | 17 | 30 | 9 | 10.8 | 18.2 | 0.028 |
| 51104 | 20 | 35 | 10 | 14.2 | 24.7 | 0.04 |
| 51105 | 25 | 42 | 11 | 19.5 | 37.2 | 0.059 |
| 51106 | 30 | 47 | 11 | 20.4 | 42.2 | 0.068 |
| 51107 | 35 | 52 | 12 | 20.4 | 44.7 | 0.09 |
| 51108 | 40 | 60 | 13 | 26.9 | 62.8 | 0.12 |
| 51109 | 45 | 65 | 14 | 27.8 | 69.1 | 0.15 |
| 51110 | 50 | 70 | 14 | 28.8 | 75.4 | 0.16 |
| 51111 | 55 | 78 | 16 | — | — | 0.24 |
| 51112 | 60 | 85 | 17 | 41.4 | 113 | 0.29 |
| 51113 | 65 | 90 | 17 | 41.7 | 117 | 0.34 |
| 51114 | 70 | 95 | 18 | 43 | 127 | 0.36 |
| 51115 | 75 | 100 | 19 | 42.3 | 127 | 0.42 |
| 51116 | 80 | 105 | 19 | 44.6 | 141 | 0.43 |
| 51117 | 85 | 110 | 19 | 45.9 | 150 | 0.46 |
| 51118 | 90 | 120 | 22 | 59.7 | 190 | 0.68 |
| 51120 | 100 | 130 | 25 | 85 | 268 | 0.99 |
3.Thrust ball Bearing pictures:
2. Thrust ball bearing 51100 application:
Applies only to bear a part of the axial load and low speed, such as crane hook, vertical pumps, vertical centrifuge, jack, low speed reducer, etc.
The shaft of the bearing ring, seat ring and rolling body is separate, can be installed separately.
