China thrust ball bearing 52202/ low friction bearings
Description of ball bearing 52202:
Product name |
52202 ball bearing |
Brand name |
KMY/OEM |
Original Packing |
(a)Neutral package & wooden package |
Precision |
P2/P4/P5/P6/P0 |
Material |
GCR-15 chrom steel,Bearing Steel |
Quality standard |
ISO9001:2000 |
Delivery date |
Within 5 working days or according to you request |
Payment terms |
A:100% T/T in advance at sight B:30%T/T in advance.70% against copy of B/L |
Features |
these bearings are featured by the extremely big axial load carrying capacity and meanwhile,they can also carry cetain radial load |
Package |
sigle box/industrial standard packing/single carton/according to buyers requirement |
Cage Material |
Bearing steel/brass |
Main market |
Mideast;Canda;Southeast Asia;South America and other countries all over the world |
Company name |
Jinan Kaiming Bearing CO.,LTD |
Contact |
Helen Gao Skype:qgbearing2013 Tel:0086-0531-85066228 Fax:0086-0531-85066708 |
2.Thrust ball bearing list:
| Thrust Ball Bearings | ID | OD | B | Cr | Cor | Weight |
| (mm) | (mm) | (mm) | (kN) | (kN) | (kg) | |
| 51105 | 25 | 42 | 11 | 19.5 | 37.2 | 0.059 |
| 51106 | 30 | 47 | 11 | 20.4 | 42.2 | 0.068 |
| 51107 | 35 | 52 | 12 | 20.4 | 44.7 | 0.09 |
| 51108 | 40 | 60 | 13 | 26.9 | 62.8 | 0.12 |
| 51109 | 45 | 65 | 14 | 27.8 | 69.1 | 0.15 |
| 51110 | 50 | 70 | 14 | 28.8 | 75.4 | 0.16 |
| 51111 | 55 | 78 | 16 | — | — | 0.24 |
| 51112 | 60 | 85 | 17 | 41.4 | 113 | 0.29 |
| 51113 | 65 | 90 | 17 | 41.7 | 117 | 0.34 |
| 51114 | 70 | 95 | 18 | 43 | 127 | 0.36 |
| 51115 | 75 | 100 | 19 | 42.3 | 127 | 0.42 |
| 51116 | 80 | 105 | 19 | 44.6 | 141 | 0.43 |
| 51117 | 85 | 110 | 19 | 45.9 | 150 | 0.46 |
| 51118 | 90 | 120 | 22 | 59.7 | 190 | 0.68 |
| 51120 | 100 | 130 | 25 | 85 | 268 | 0.99 |
3.Thrust ball Bearing 52202 pictures:
4. Application of ball bearing 52202
Thrust ball bearing 52202 applies only to bear part of the axial load and low speed, such as crane hook, embroidery machine, vertical pumps, vertical centrifuge, jack, low speed reducer, etc.
The shaft of the bearing ring, seat ring and rolling body is separate, can be installed separately.
5.Mainly bearing type:
angular contact ball bearings |
slewing bearing special bearings axial load ball bearing 52210 |
