Waterproof Anemometer Portable Meteorological Wind Speed Meter NK5916
NK5916 wind meter is the world's leading meteorological wind speed meter, fully combine their technical superiority.
NK5916 meteorological wind speed detector uses a high-performance single-chip microprocessor, NK5916 meteorological
wind speed meter is with leading instrument technology, equipment maintenance down to a minimum; NK5916
meteorological wind speed meter is in accordance with internationally accepted standards, to meet the field-site,
emergency and routine laboratory monitoring of various indicators measuring the wind speed; ingenious design,
NK5916 meteorological wind speed detector satisfied with anti-vibration, waterproof ( IP67), multi-purpose (conventional, on-site and emergency), enables users to lower investment, to ensure that users not only apply
to the measurement requirements under various environmental field, also applies to emergencies fast measurement process,
NK2000 wind speed Meteorological instrument for accurate information on the environmental monitoring of meteorological
data, and access to accurate and reliable data protection.
NK5916 meteorological wind speed meter feature:
1.Patented microprocessing technology, user-friendly design, large screen back-light display, measuring process graphic display, simpleoperation;
2.The unique combination of philosophy, can quickly measure conventional or conventional wind speed indicators; and storing the last measurement data;
3.The unique design of humanity, according to the specific circumstances and field conditions to achieve a variety of indicators measuring;
4.Conventional power configuration, low battery indicator, can be based on user needs to set 45 minutes automatic shutdown;
5.The portable packaging, waterproof, anti-vibration design, supplies the economy for a variety of conditions and monitoring and measurement data
security in various industries.
NK5916 Wind Meter Basic Parameters
| Measuring Response Time | Unit | Range | Resolution | Accuracy | Limit Range |
| Wind speed (air flow rate) 1 second | m/s | 0.4 to 60.0m/s | 0.1 | Greater than 3% of reading or least significant digit | 0.4 to 40.0m/s |
| ft/min | 59 to 11948ft/min | 1 | 59 to 7877ft/min | ||
| km/h | 1.0 to 218.0km/h | 0.1 | 1.0 to 144.0km | ||
| mph | 0.8 to 135.0mph | 1 | 0.8 to 89.0mph | ||
| knots | 0.6 to 118.3kt | 0.1 | 0.6 to 78.0kt | ||
| beaufort | 0 to 12B | 0.1 | 0 to 12B | ||
| 1 inch diameter impeller with precision axle, sapphire bearings, air shaft accuracy -1% @ 5 °; -2% @ 10 °; -3% @ 5 °, after use in 16MPH / 7m / s 100 hour calibration drift <1%, if continuous measurements 60MPH / 27m / s, the impeller will quickly wear and damage, replace the impeller (NK30801) the use of special tools (US Patent No. 5,783,753). | |||||
| Temperature 1 second | ℉ | -49.0 to 257.0℉ | 0.1 | 1.8℉ | -20 to 158.0℉ |
| ℃ | -45.0 to 125.0℃ | 0.1 | 1.0℃ | -29.0 to 70.0℃ | |
| Measure air, water, snow temperature, thermal isolation, sealing device, so that the thermal to maintain maximum precision value (US Patent No. 5,939,645), calibration drift can be ignored. | |||||
| Wind chill index 1 second | ℉ | 0.7 to 135MPH,-49 to 257℉ | 0.1 | 1.8℉ | 1.8 to 89.0MPH -50 to 50 ℉ |
| ℃ | 0.4 to 60.0m/s,-45 to 125℉ | 0.1 | 1.0℃ | 0.4 to 40m/s,-45.6 to 10 ℃ | |
NK5916 Wind Meter Technical Parameters
Maximum (average) wind speed | One-touch open and close the maximum wind speed and average wind speed measurements |
Data download | You need to select the PC interface (NK PN-0830), to provide a soft, RS-232 interface connection, USB adapter |
Screen display | 31/2 character LCD display, character height 0.36 inch / 9mm |
Screen Update | 1 second |
Screen background light | green |
Operating temperature (screen / battery) | Operating temperature range: LCD screens and batteries are -10 ℃ to 55 ℃ / 14 ℉ to 131 ℉, if the operating temperature exceeds this limit, the instrument may be damaged in need of repair. |
Temperature Storage | Range -30℃ to 60℃/-22℉ to 140℉ |
Automatic shut-down | automatic shutdown after 45 minutes without any operation |
Certificate | CE standard.Individual test NIST-- traceable standards |
Battery | CR2032, one built-in, with an average life of 300 hours, life influence by using back lighting |
Seal | Waterproof (IP67 standard) |
Size | Indicator 4.8×1.7×0.7 inch 122×42×18mm. Packing box:4.8×1.9×1.1 inch 122×42×28mm |
Weight | Indicator 2.3ang/65 g. Packing box 1.3ang/37g |
NK5916 wind meter configuration | |
| NK5916 | Four meteorological parameters measured, batteries, carrying strap, protective cover, English Manual, suitable for: Instant wind speed, maximum wind speed, average wind speed, wind chill index and other indicators' |
