High-speed Specialized Slip Ring : HGT1254-6
Negotiable
MOQ: 10 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
China
Brand Name:
Grand Technology
Model Number:
HGT1254-6
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
High Speed Slip Rings Slip RingNegotiableMOQ: 10 Units -
High Speed Slip Rings Slip RingUS$ 100 - 200MOQ: 10 Units
-
High Speed Slip Rings Slip RingNegotiableMOQ: 10 Units
-
High Speed Electrical Slip Rings Marine and Medical Equipment SlipringUS$ 100 - 200MOQ: 10 Units
-
High Speed Electrical Slip Rings Marine and Medical Equipment Slip Ring ElectricalUS$ 100 - 200MOQ: 10 Units
Place of Origin
China
Brand Name
Grand Technology
Model Number
HGT1254-6
Precision ball bearings and the patented fiber brush design allow operation up to 6,000 rpm. Fiber brush technology offers several advantages over conventional slip ring contacts including multiple points of contact per brush bundle, low contact force per fiber and low contact wear rates. In addition, fiber brushes do not require lubrication and produce virtually no wear debris
Options
No. of circuits Wire length
Operation speed, current &voltage
Flange mounting Protection level (dust and water)
Connector Signal,power and data transmitted or
Housing material combination transmitted
Inner diameter
Housing color
Position of wire outlet
| Electrical Parameters | |
| Circuit | 6 rings |
| Rated Voltage | 380VAC/240VDC |
| Rated Current | 2A/5A/10A/15A |
| Dielectric Strength | 1000VAC@50Hz,60s between each circuit |
| Insulation Resistance | 1000MΩ/500VDC |
| Electrical Noise | <0.01Ω |
| Lead length | Standard 250mm |
| Machinery Technology Parameter | |
| Operating Speed | 0-5,000rpm |
| Working Temperature | -20℃ - +80℃ |
| Working Humidity | 75%RH or higher |
| Contact Material | Precious Metal |
| Bearing | Steel ball bearings |
| Structure Material | Engineering Plastic or metal |
| Torque | 0.1N/m for 6 rings, 0.03N/m increased for every 6 rings added |
| IP Rating | IP 54 |
| Operational life |
≥200 million cycles(Depends upon working temperature,rotating speed, environment and continuous working time) |
Outline dimesion unit
