Product Details
Place of Origin: | China | Brand Name: | New Light | Model Number: | 2753 |
Type: | Insulation Sleeving | Material: | Other, silicone resin and fiberglass | Application: | High Voltage |
Rated Voltage: | 1.5 -10 KV |
Product Description
2753 silicone resin coated fiberglass sleeving
2753 Silicone Resin Fiberglass Sleeve
1.Description
Silicone fiberglass sleeving is braided with non-alkali fiberglass yarn and then coated with silicone resin. It possesses good properties of dielectric, heat resistance, self-extinguishing, softness and elasticity etc.
2. Specification2.
1).Packing: 50-100m/roll,or according to clients' request.
2).Diameter: 0.5-30 mm
3).Thermal class: H
4). Breakdown voltage: 1.5kV to 10.0kV
5). Operating temperature: -60℃ to 180℃
6). Short time peaks at 250℃
3.Color: white,other colors is also available according to request.
4.Applications: its widely used for the insulating protection of H class motor, electrical and electronic equipments.
Inner Diameter(mm) | Wall Thickness(mm) | ||
Nominal | Tolerance | Nominal | Tolerance |
0.5 | ±0.15 | 0.50 | ±0.15 |
1, 1.5, 2, 2.5 | ±0.20 | 0.50 | ± 0.15 |
3, 4, 5, 6 | ±0.25 | ||
8, 9, 10 ,12 | ±0.30 | 0.70 | ± 0.20 |
14,16,18,20 | ±0.50 | 0.70 | ±0.30 |
25 | ±0.60 | 1.0 | ±0.50 |
30 | ±0.60 | 1.5 | ±0.50 |
