Help Centerthe Filter Module for PDU Socket
US$ 1 - 10
MOQ: 500 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
LUCKTEK
Grounding:
Standard Grounding
Payment & Shipping
Payment Methods:
Port of Shipment:
ningbo
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
High Quality 3 PIN South Africa PlugUS$ 1 - 10MOQ: 500 Pieces -
6 WAY South Africa USB Extension Power Socket OutletUS$ 1 - 10MOQ: 500 Pieces
-
4 WAY South Africa Extension Power Strip With Battery ChargerUS$ 1 - 10MOQ: 500 Pieces
-
6ways UK Power Extension Socket With USB ChargerUS$ 1 - 20MOQ: 1 Piece
-
6ways UK Power Extension Socket With Surge Protection & BT Telephone JackUS$ 1 - 20MOQ: 1 Piece
Place of Origin
Zhejiang, China
Brand Name
LUCKTEK
Grounding
Standard Grounding
Rated Voltage
220-250
Rated Current
16AMP
Application
Residential / General-Purpose
Specifications
the filter module for PDU socketLowest price
Best Quality
the filter module for PDU socket
- Color: Green
- Working temperature: -20'C~60'C
- Relative humidity: 40%~90%RH
- Input voltage range: AC 85V~265V
- Input current: 0.0273(AC110V), 0.014(AC220V)
- Input surge current: 20A
- Output voltage range: 11.9 ~ 12.1V
- Output Current Range: 0A to 1000mA
- Peak current: 1300mA
- Output power: 12W (Max. 15W)
- Output efficiency: 85%
- Switching machine overshoot: 10%
- Output rise time: 100mA
- Output power protection: recovery characteristics: lock, restart and recovery
- Short circuit protection: recovery characteristics: lock, reboot recovery
- Temperature protection: recovery characteristics: lock up, restart and recovery
- Over current protection: recovery characteristics: lock, restart and recovery
- Under environment 25 'C, 80% load conditions, MTBF greater than 16,000 hours
- Working temperature: -20'C~60'C
- Relative humidity: 40%~90%RH
- Input voltage range: AC 85V~265V
- Input current: 0.0273(AC110V), 0.014(AC220V)
- Input surge current: 20A
- Output voltage range: 11.9 ~ 12.1V
- Output Current Range: 0A to 1000mA
- Peak current: 1300mA
- Output power: 12W (Max. 15W)
- Output efficiency: 85%
- Switching machine overshoot: 10%
- Output rise time: 100mA
- Output power protection: recovery characteristics: lock, restart and recovery
- Short circuit protection: recovery characteristics: lock, reboot recovery
- Temperature protection: recovery characteristics: lock up, restart and recovery
- Over current protection: recovery characteristics: lock, restart and recovery
- Under environment 25 'C, 80% load conditions, MTBF greater than 16,000 hours
Dimensions: 2.64 in x 1.22 in x 0.79 in (6.7 cm x 3.1 cm x 2.0 cm)
Weight: 1.06 oz (30 g)
