18U/22U/27U/32U/37U/42U/45U/47U Floor Server Cabinet
- Ningbo/Shanghai
- T/T L/C D/P D/A Credit Card
You May Like
Product Details
| Products Status | Stock | Cabinet Standard | ANS/EIA RS-310-D, IEC297-2, DIN41491, PART1, DIN41491, PART7, ETSI | |
| Material | SPCC quality cold rolled steel | Size | 18U/22U/27U/32U/37U/42U/45U/47U | |
| Place of Origin | Zhejiang, China | Brand Name | OEM | |
| Model Number | LK-JS6842 |
Product Description
Specifications
-Quality Approved-Competitive price
-Quick Delivery time
JS Server Cabinet
Feature:
Exquisite design with precise craftsmanship;
Welded steel frame for front and back part, can be flat packing, easy to transfer;
High-density vented front and rear door with hexagonal holes, can turn over 18degree;
Removable side panel, easy to install and optional lock;
Adjustable feet and castors are available at the same time;
Adjustable cable entry on the top, bottom with cable entrance;
Advanced handle locks for front door, optional other lock;
S-shaped mounting profile, free to move forward and back;
Efficient baying kit of cabinet, earthing kit;
Optional plinth to fix cabinet on floor, under base cable entry;
Various optional Accessories for common use;
Unassembled packing, flat packing, about 2/5 of original volume, save container space
Standard:
Comply with ANS/EIA RS-310-D, IEC297-2, DIN41491, PART7, DIN41491, PART7, ETSI Standard
Material:
SPCC quality cold rolled steel
Thickness: Mounting profile: 2.0mm, mounting angle: 1.5mm; others: 1.2mm
Loading Capacity:
Static loading: 800kg (on the adjustable feet)
Degree of protection:
IP20
Surface Finish:
Degreaseing, Pickling, Phosphating, Powder Coated
Details:
Certifications:
Factory Show:
