1.2v 1800mah NI-MH Batteria

Negotiable MOQ: 1000 Pieces (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Guangdong, China

Model Number:

nimh battery 1.2v

Type:

NI-MH

Shenzhen Anjcell Technology Co., Limited

Payment & Shipping

Payment Methods:

Port of Shipment:

shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Model Number nimh battery 1.2v

Type NI-MH

Nominal Voltage 1.2V

Size AAA

Nominal Capacity 850mah/1800MAH ETC

Specifications

Nominal Voltage 1.2v
Nominal Capacity 850mah
Minimum Capacity 820mAh
Standard Charge 85mA(0.1C) *16 hrs

Test	Specification	Conditions	Remarks
Capacity	≥820mAh	Standard Charge/Discharge	Up to 3 cycles are allowed
Open Circuit Voltage(OCV)	≥1.25V	Within 1hr after standard charge
Internal Impedance (Ri)	≤50	Upon fully charge(1000Hz)
High Rate Discharge (0.5C)	≥104min	Standard Charge, 1hr rest before discharge
High Rate Discharge ( 1 C)	≥49min	Standard Charge, 1hr rest before discharge
Overcharge	No leakage nor explosion	85mA(0.1C) charge 28 days
Charge Retention	≥510mAh	Standard Charge, Storage:28 days, Standard Discharge
IEC Cycle Test	≥500 Cycle	IEC 61951-2:2003	(see Note 3)

Description	Specification	Conditions
Nominal Voltage	1.2 V
Nominal Capacity	850mAh	Standard Charge/Discharge
Minimum Capacity	820mAh	Standard Charge/Discharge
Standard Charge	85mA(0.1C) × 16 hrs	Ta=0~45°C(see Note 1)
Rapid Charge	255mA(0.3C) ×3.6 hrs approx. (see Note 2)	Timer CutOff =105% dT/dt= 1~2°C/3min Temp. CutOff = 50°C (122°F) Ta=10~45°C
Trickle Charge	42.5-85.0mA(0.05C-0.1C)	Ta=0~45°C
Discharge Cut-off Voltage	1.0V
Maximum Discharging Current	850mA(1C)	Ta= -20°C~50°C
Storage Temperature	-20°C~35°C	Discharged state
Typical Weight(approximate)	13.5 g
