Home > Products > Powder coatings > Rough finish epoxy polyester powder coating
Rough finish epoxy polyester powder coating
- 200 Ton / Tons per Month
- Shanghai/ningbo
- T/T L/C D/P D/A Credit Card PayPal
- Aeropak premium Shoe Care - Instant Sneaker Cleaner Foam 250ml manufacturer
- AEROPAK Chain lube oil
- Aeropak Popular Series Tyre sealer inflator
- Aeropak Acrylic Spray Paint Aerosol Color Spray
- Aeropak fast dry spray paint acrylic Aeroso Spray Paint factory
- Aeropak Metallic AUTO SPRAY PAINT manufacturer/factory (SGS/ROHS)
Product Details
CAS No.: | 113669-95-7 | Other Names: | Rough finish epoxy polyester powder coating | MF: | Mixture |
EINECS No.: | nh | Place of Origin: | Shanghai, China | Main Raw Material: | Other, polyester resin |
Usage: | Car Paint, Electrical Insulating Varnish, Furniture Paint | Application Method: | Other, Spray, spray | State: | Powder Coating |
Brand Name: | NH | Model Number: | NH1039 |
Product Description
Rough finish epoxy polyester powder coating
Main features
1.Good leveling property
2. High gloss;
3. Excellent physical and mechanical performance;
4. Excellent resistance to chemicals;
5. Good resistance to heat.
Application
It is applicable to the coating of all household appliances, instruments, meters, light industrial products, office equipment, library equipment, electromechanical equipment and other metal products.
Type of powder coating
Technical indexes
Residue on sieve %125μm | 0 or based on negotiation |
Color and appearance of paint film | The paint film should be smooth but slight orange peel is allowed and the color should meet the color difference specified. |
Hardness | ≥2 H |
Bending mm | 2 |
Gloss (60°) | ≤20 |
Adhesive force (1×1 mm) Grade 6×6 | 0 |
Impact resistance kg.cm | ≥40 |
Acid resistance (HCI 3%)240 h | The paint film has no change. |
Alkali resistance (NaOH 5%) 168 h | Slight change is allowed but it shall be recovered within 2h |
Salt spray resistance 400 h | ≤ Grade 1 |
Damp-heat resistance 500 h | ≤ Grade 1 |
Film thickness μm | 50~60 |
Surface prepartion
The corresponding treatment method should be used based on the substrates, such as phosphating, chromizing,shot blasting or blast cleaning
1. The surface roughness should be 30 ~75 μm if reaching Grade Sa2.5 by shot blasting or blast cleaning.
2. Phosphating: degreasing- derusting- neutralizing- surface control- phosphating- passivating
Appearance of phosphating film: The phosphating film should be crystallized densely, continuously and evenly.
3. Chromizing: degreasing- rinsing- immersion cleaning- deoxidating- rinsing- chromizing
Method of Application
It is applicable to high voltage electrostatic spraying
Spraying voltage: 50-90 kV; air pressure for spraying: 0.1-0.2 Mpa;
Distance between the gun and workpiece: 200-300 mm
Curing condition: 200℃/15 minutes or customized according to customers’ requirements.
Additional coating: spraying and curing should be made after polishing the omitted part with sand paper and spraying the whole surface.
Shanghai NH Trade Co., Ltd. is a manufacturer of oil paint with well-equipped testing equip-ment and strong technical force. Our company was established in 2004 and registered the independent paint brand of "NH New Emperor" in 2008.
Till now,We have strongly enhanced our market in chemical,textile,argriculture,building,biological,automotive field and so on.Our company has the industry`s most advanced and sophisticated production facilities.Strict supervision on the quality of our products will make sure you`re 100% satisfied with us.
Tel: 86 021 54880584 fax: 86 021 54880897-8008 E-mail: lynnhuang_nh#
Add: No. 7001 zhongchun road, Minhang district, Shanghai, China
In NH, you could enjoy these services:
If you have any problem in technique or paints, we would help you winthin 24 hrs;
We could offer a video of construction if you need.
We could offer technical guidance. If your project have trouble in
the construction technique, we could arrange a technical person
to your country to demonstrate for you. And we even could
arrange a construction team to help you if your project is big enough.
1.Why Choose us?
100% factory products
The delivery is assurable, the price is reasonable for we have our own factory
All our products is high performance and good quality
NH has more than 30 years experience in paints / coating , so we could offer professional scheme
2. What's your MOQ (min order quantity) ?
Our MOQ is 1000Kg, and we accept mixed order.
3. Sample is free?
We offer free sample.
You could choose sample board or sample paint
4. Which certificates do you have?
Usually, we have ISO 9001, ISO 12944, SGS , ROHS, CNAS, IAF, MSDS...
We could help you to test the products according to your country's request.
