On Sales 2MP Full HD Box CCTV Camera

US$ 1 - 1,000 MOQ: 1 Piece

Key Specifications

Place of Origin:

China

Brand Name:

GSM

Model Number:

GSM-NC-22004

Guangzhou SM International Trade Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Guangzhou

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin China

Brand Name GSM

Model Number GSM-NC-22004

Type Analog Camera

Style Box Camera

Sensor CMOS

Technology NetWork

Special Features Vandal-proof

Specifications

1, High Quality and good price
2, Small oder accepted
3, Do OEM as respected
4, Design as respected

On sales 2MP Full HD Box CCTV Camera

Camera

Image Sensor:	1/2.8" Progressive Scan CMOS
Signal System:	PAL/NTSC
Min. Illumination:	Color: 0.02 Lux @ (F1.2, AGC ON) B/W: 0.005 Lux @ (F1.2, AGC ON)
Shutter time:	1 s to 1/100,000 s
Lens Mount:	C/CS mount
Auto Iris:	DC drive(-P: support P-Iris)
Day& Night:	IR cut filter with auto switch
Wide Dynamic Range:	Digital WDR
Digital noise reduction:	3D DNR
Focus:	ABF(-A model)

Compression Standard


Max. Image Resolution:	1920 x 1080
Frame Rate:	50Hz: 25fps (1920 × 1080) 25fps (1280 × 960), 25fps (1280 × 720) 60Hz: 30fps (1920 × 1080) 30fps (1280 × 960), 30fps (1280 × 720)
Third Stream:	Independent with Main Stream and Sub Stream, up to 50Hz: 25fps (1920 × 1080) 60Hz: 30fps (1920 × 1080)
Image Settings:	Rotate mode, Saturation, Brightness, Contrast adjustable by client software or web browser
BLC:	Support
HLC:	Support
Smart Defog:	Support
EIS:	Support
ROI:	Yes, up to 4 configurable areas
Picture Overlay:	128 × 128, BMP 24bit, zone configurable

Network

Network Storage:	NAS
Alarm Trigger:	Intrusion detection, Defocus detection, Motion detection, Face detection, Dynamic analysis, Tampering alarm, Network disconnect, IP address conflict, Storage exception
Protocols:	TCP/IP,ICMP,HTTP,HTTPS,FTP,DHCP,DNS,DDNS,RTP,RTSP,RTCP, PPPoE,NTP,UPnP,SMTP,SNMP,IGMP,802.1X,QoS,IPv6,Bonjour(SIP optional)
Security:	User Authentication, Watermark, IP address filtering, anonymous access
System Compatibility:	ONVIF, PSIA, CGI

Interface

Audio Input:	1-ch 3.5 mm audio interface, Mic in/Line in. 1 built-in Microphone
Audio Output:	1-ch 3.5mm audio interface (line level, 600 Ω)
Communication Interface:	1 RJ45 10M/100M Ethernet port, 1 RS-485 interface and 1 RS-232 interface
Alarm Input:	1
Alarm Output:	1
Video Output:	1Vp-p Composite Output (75 Ω, BNC)
On-board storage:	Built-in Micro SD/SDHC/SDXC card slot, up to 64 GB
Reset Button:	Yes

Wi-Fi Specification (-W)

Wireless Standards:	IEEE802.11b, 802.11g, 802.11n Draft
Frequency Range:	2.4 GHz ~ 2.4835 GHz
Channel Bandwidth:	20/40MHz Support
Modulation Mode:	802.11b: CCK, QPSK, BPSK 802.11g/n: OFDM
Security:	64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK, WPS
Transmit Power:	11b: 17±1.5dBm @ 11Mbps 11g: 14±1.5dBm @ 54Mbps 11n: 12.5±1.5dBm
Receive Sensitivity:	11b: -90dBm @ 11Mbps (Typical) 11g: -75dBm @ 54Mpbs (Typical) 11n: -74dBm (Typical)
Transmission Rate:	11b: 11Mbps 11g: 54Mbps 11n: up to 150Mbps
Wireless Range:	Outdoor: 200m,Indoor: 50m(depend on environment)

General

Operating Conditions:	-30 °C ~ 60 °C (-22 °F ~ 140 °F) Humidity 95% or less (non-condensing)
Power Supply:	24V AC, ±10% / 12V DC, ±10% , PoE(Power Over Ethernet)
Power Consumption:	Max. 6 W (Max. 9W with IR cut filter on) -W: Max. 7 W (Max. 10W with IR cut filter on)
Dimensions:	69.8×58×145 mm (2.68” × 2.56” × 5.70”)
Weight:	830 g (1.83 lbs)
