On Sale 5MP Network Box CCTV Camera

US$ 1 - 1,000 MOQ: 1 Piece

Key Specifications

Place of Origin:

China

Brand Name:

GSM

Model Number:

GSM-NC52201

Guangzhou SM International Trade Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Guangzhou

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin China

Brand Name GSM

Model Number GSM-NC52201

Type Other, Analog Camera, Network Camera

Style Box Camera

Sensor CMOS

Technology NetWork

Special Features Vandal-proof

Specifications

1, High Quality and good price
2, Small oder accepted
3, Do OEM as respected
4, Design as respected

On Sale 5MP Network Box CCTV Camera

Camera

Image Sensor:	1/2.5" Progressive Scan CMOS
Min. Illumination:	Color: 0.6 lux@ F1.2, AGC on B/W: 0.08 lux @ F1.2, AGC on
Shutter time:	1/25s ~ 1/100,000s
Lens Mount:	C/CS mount
Auto Iris:	DC drive
Day& Night:	IR cut filter with auto switch

Compression Standard


Max. Image Resolution:	2560×1920
Frame Rate:	50 Hz: 6.25 fps (2560 × 1920) 12.5 fps (2048 × 1536) 25 fps (1920 × 1080) 25 fps (1600 × 1200) 25 fps (1280 × 720) 60 Hz: 7.5 fps (2560 × 1920) 15 fps (2048 × 1536) 30 fps (1920 × 1080) 30 fps (1600 × 1200) 30 fps (1280 × 720)
Image Settings:	Saturation, brightness, contrast adjustable through client software or web browser

Network

Network Storage:	NAS (iSCSI optional)
Alarm Trigger:	Motion detection, tampering alarm, network disconnect , IP address conflict, storage exception
Protocols:	TCP/IP, HTTP, DHCP, DNS, DDNS, RTP/RTSP, PPPoE, SMTP, NTP, SNMP, HTTPS,FTP,802.1x, Qos (SIP, SRTP, IPv6 optional)
Security:	User authentication, watermark
System Compatibility:	ONVIF, PSIA, CGI

Interface

Audio Input:	1-ch 3.5 mm audio interface, MIC IN/LINE IN
Audio Output:	1-ch 3.5mm audio interface (line level, 600 Ω)
Communication Interface:	1 RJ45 10M / 100M ethernet interface and 1 RS-485 interface
Alarm Input:	1
Alarm Output:	1
Video Output:	1Vp-p Composite Output (75 Ω, BNC)
On-board storage:	Built-in SD/SDHC slot, up to 32 GB
Reset Button:	Yes

General

Operating Conditions:	-10 °C ~ 60 °C (14 °F ~ 140 °F) Humidity 90% or less (non-condensing)
Power Supply:	12 VDC ± 10%, PoE (802.3af)
Power Consumption:	max. 5W (max. 8W with IR cut filter on) -W: max. 7W (max. 10W with IR cut filter on)
Dimensions:	68 × 64.9 × 144.8 mm (2.68” × 2.56” × 5.70”)
Weight:	500g (1.1lbs)
