High Quality Security Camera 1.3MP IR Cube Network CCTV Camera GSM-NC15602

Guangzhou SM International Trade Co., Ltd.

US$ 1 - 800 MOQ: 1 Piece

Key Specifications

Place of Origin:

China

Brand Name:

GSM

Model Number:

GSM-NC15602

Payment & Shipping

Payment Methods:

Port of Shipment:

Guangzhou

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin China

Brand Name GSM

Model Number GSM-NC15602

Style Other, cube

Sensor CMOS

Technology NetWork

Special Features Waterproof / Weatherproof

Specifications

1.Good quality
2.Competitive price.
3.Prompt delivery
4.Accept small order.
5.Condition:new and original

high quality Security camera 1.3MP IR Cube Network CCTV Camera GSM-NC15602

Product Description

Camera

Image Sensor:	1/3" Progressive Scan CMOS
Min. Illumination:	0.01Lux @ (F1.2, AGC ON),0 Lux with IR
Shutter time:	1/25(1/30) s to 1/100,000 s
Lens:	4mm@ F2.0 (2.8mm, 6mm optional) Angle of view: 92.5°(2.8mm), 73.1°(4mm), 46°(6mm)
Lens Mount:	M12
Day& Night:	IR cut filter with auto switch
Wide Dynamic Range:	Digital WDR
Digital noise reduction:	3D DNR

Compression Standard


Max. Image Resolution:	1280x960
Frame Rate:	50 Hz: 25 fps (1280 × 960), 25 fps (1280 x 720), 25 fps (704 x 576), 25 fps (640 x 480) 60 Hz: 30 fps (1280 × 960), 30 fps (1280 x 720), 30 fps (704 x 576), 30 fps (640 x 480)
Image Settings:	Rotate mode, Saturation, Brightness, Contrast adjustable by client software or web browser
BLC:	Yes, zone configurable
ROI:	Yes, up to 4 configurable areas

Network

Network Storage:	NAS
Alarm Trigger:	Motion detection, Dynamic Analysis, Tampering alarm, Network disconnect, IP address conflict, Storage exception
Protocols:	TCP/IP,ICMP,HTTP,HTTPS,FTP,DHCP,DNS,DDNS,RTP,RTSP,RTCP, PPPoE,NTP,UPnP,SMTP,SNMP,IGMP,802.1X,QoS,IPv6,Bonjour
Security:	User Authentication, Watermark, IP address filtering, anonymous access
System Compatibility:	ONVIF, PSIA, CGI, ISAPI

Interface

Audio:	Internal Microphone and Speaker
Communication Interface:	1 RJ45 10M / 100M ethernet interface
On-board storage:	Built-in Micro SD/SDHC/SDXC card slot, up to 64 GB
Reset Button:	Yes

Wi-Fi Specification (-W)

Wireless Standards:	IEEE802.11b, 802.11g, 802.11n Draft
Frequency Range:	2.4 GHz ~ 2.4835 GHz
Channel Bandwidth:	20/40MHz Support
Modulation Mode:	802.11b: CCK, QPSK, BPSK 802.11g/n: OFDM
Security:	64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK, WPS
Transmit Power:	11b: 17±1.5dBm @ 11Mbps 11g: 14±1.5dBm @ 54Mbps 11n: 12.5±1.5dBm
Receive Sensitivity:	11b: -90dBm @ 11Mbps (Typical) 11g: -75dBm @ 54Mpbs (Typical) 11n: -74dBm (Typical)
Transmission Rate:	11b: 11Mbps 11g: 54Mbps 11n: up to 150Mbps
Wireless Range:	Outdoor: 200m,Indoor: 50m(depend on environment)

General

Operating Conditions:	-30 °C ~ 60 °C (-22 °F ~ 140 °F) Humidity 95% or less (non-condensing)
Power Supply:	12 VDC ± 10%, PoE (802.3af)
Power Consumption:	5W MAX
IR Range:	10 meters
PIR:	Angle of detection: 80° Detection range: 10 meters
Dimensions:	66×91.5×131.3(2.60”×3.60” ×5.17”)
Weight:	400g(0.88lbs)
