High Quality Security Camera 1.3MP IR Cube Network CCTV Camera GSM-NC15602

High Quality Security Camera 1.3MP IR Cube Network CCTV Camera GSM-NC15602 photo-1
US$ 1 - 800 MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
China
Brand Name:
GSM
Model Number:
GSM-NC15602
Payment & Shipping
Payment Methods:
Port of Shipment:
Guangzhou
Delivery Detail:
Delivery time depends on order quantity.
Place of Origin China
Brand Name GSM
Model Number GSM-NC15602
Style Other, cube
Sensor CMOS
Technology NetWork
Special Features Waterproof / Weatherproof

Specifications

1.Good quality
2.Competitive price.
3.Prompt delivery
4.Accept small order.
5.Condition:new and original

high quality Security camera 1.3MP IR Cube Network CCTV Camera GSM-NC15602



Product Description
Camera
Image Sensor: 1/3" Progressive Scan CMOS
Min. Illumination: 0.01Lux @ (F1.2, AGC ON),0 Lux with IR
Shutter time: 1/25(1/30) s to 1/100,000 s
Lens: 4mm@ F2.0 (2.8mm, 6mm optional) Angle of view: 92.5°(2.8mm), 73.1°(4mm), 46°(6mm)
Lens Mount: M12
Day& Night: IR cut filter with auto switch
Wide Dynamic Range: Digital WDR
Digital noise reduction: 3D DNR
Compression Standard
Video Compression: H.264/M-JPEG
Bit Rate: 32 Kbps ~ 16 Mbps
Audio Compression: G.711/G.726/MP2L2
Dual Stream: Yes
Max. Image Resolution: 1280x960
Frame Rate: 50 Hz: 25 fps (1280 × 960), 25 fps (1280 x 720), 25 fps (704 x 576), 25 fps (640 x 480) 60 Hz: 30 fps (1280 × 960), 30 fps (1280 x 720), 30 fps (704 x 576), 30 fps (640 x 480)
Image Settings: Rotate mode, Saturation, Brightness, Contrast adjustable by client software or web browser
BLC: Yes, zone configurable
ROI: Yes, up to 4 configurable areas
Network
Network Storage: NAS
Alarm Trigger: Motion detection, Dynamic Analysis, Tampering alarm, Network disconnect, IP address conflict, Storage exception
Protocols: TCP/IP,ICMP,HTTP,HTTPS,FTP,DHCP,DNS,DDNS,RTP,RTSP,RTCP, PPPoE,NTP,UPnP,SMTP,SNMP,IGMP,802.1X,QoS,IPv6,Bonjour
Security: User Authentication, Watermark, IP address filtering, anonymous access
System Compatibility: ONVIF, PSIA, CGI, ISAPI
Interface
Audio: Internal Microphone and Speaker
Communication Interface: 1 RJ45 10M / 100M ethernet interface
On-board storage: Built-in Micro SD/SDHC/SDXC card slot, up to 64 GB
Reset Button: Yes
Wi-Fi Specification (-W)
Wireless Standards: IEEE802.11b, 802.11g, 802.11n Draft
Frequency Range: 2.4 GHz ~ 2.4835 GHz
Channel Bandwidth: 20/40MHz Support
Modulation Mode: 802.11b: CCK, QPSK, BPSK 802.11g/n: OFDM
Security: 64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK, WPS
Transmit Power: 11b: 17±1.5dBm @ 11Mbps 11g: 14±1.5dBm @ 54Mbps 11n: 12.5±1.5dBm
Receive Sensitivity: 11b: -90dBm @ 11Mbps (Typical) 11g: -75dBm @ 54Mpbs (Typical) 11n: -74dBm (Typical)
Transmission Rate: 11b: 11Mbps 11g: 54Mbps 11n: up to 150Mbps
Wireless Range: Outdoor: 200m,Indoor: 50m(depend on environment)
General
Operating Conditions: -30 °C ~ 60 °C (-22 °F ~ 140 °F) Humidity 95% or less (non-condensing)
Power Supply: 12 VDC ± 10%, PoE (802.3af)
Power Consumption: 5W MAX
IR Range: 10 meters
PIR: Angle of detection: 80° Detection range: 10 meters
Dimensions: 66×91.5×131.3(2.60”×3.60” ×5.17”)
Weight: 400g(0.88lbs)



 high quality Security camera 1.3MP IR Cube Network CCTV Camera GSM-NC15602



Packaging & Shipping



priceFOB
ShipmentBy Express/Air/Ship
PaymentByT/T /Western Union
PortGuangzhou,CHINA
Delivery TimeWithin one week

 high quality Security camera 1.3MP IR Cube Network CCTV Camera GSM-NC15602

Our Services

      we supply thousand kinds of products including brands like NCR, WINCOR, FUJITSU, HITACHI, GRG, YH.

    we do OEM for our customers according to your needs.

    our after-sale service is reliable.

high quality Security camera 1.3MP IR Cube Network CCTV Camera GSM-NC15602 high quality Security camera 1.3MP IR Cube Network CCTV Camera GSM-NC15602high quality Security camera 1.3MP IR Cube Network CCTV Camera GSM-NC15602
