Security Camera 1.3MP WDR Pinhole Covert Network Camera GSM-NC14801

US$ 1 - 800 MOQ: 1 Piece

Key Specifications

Place of Origin:

Guangdong, China

Model Number:

GSM-NC14801

Style:

Hidden Camera

Guangzhou SM International Trade Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

guangzhou

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Model Number GSM-NC14801

Style Hidden Camera

Sensor CMOS

Technology NetWork

Special Features Waterproof / Weatherproof

Specifications

1.accept small
mpt deliver
ndition:new original
4.payment:WU/TT

Security camera 1.3MP WDR Pinhole Covert Network Camera GSM-NC14801

Product Description

Camera

Image Sensor:	1/3" Progressive Scan CMOS
Min. Illumination:	Color: 0.01lux @(F1.2, AGC ON) B/W: 0.001lux @(F1.2, AGC ON)
Shutter time:	1s ~ 1/100,000s
Lens:	4mm @ F2.0, angle of view: 73.1 ° (2.0mm, 2.8mm, 6mm, optional)
Lens Mount:	M12
Day& Night:	Electronic
Wide Dynamic Range:	120 dB
Digital noise reduction:	3D DNR

Compression Standard


Max. Image Resolution:	1280x960
Frame Rate:	50Hz: 25fps (1280 × 960), 25fps (1280 × 720) 60Hz: 30fps (1280 × 960), 30fps (1280 × 720)
Third Stream:	50Hz: 25fps (1280 × 960) 60Hz: 30fps (1280 × 960)
Image Settings:	Rotate mode, Saturation, Brightness, Contrast adjustable by client software or web browser
BLC:	Yes, zone configurable
HLC:	Support
ROI:	Max. 4 ROI areas
Picture Overlay:	128 x 128, BMP 24bit, zone configurable

Network

Network Storage:	NAS
Alarm Trigger:	Intrusion detection, Defocus detection, Motion detection, Face detection, Dynamic analysis, Tampering alarm, Network disconnect, IP address conflict, Storage exception
Protocols:	TCP/IP,ICMP,HTTP,HTTPS,FTP,DHCP,DNS,DDNS,RTP,RTSP,RTCP, PPPoE,NTP,UPnP,SMTP,SNMP,IGMP,802.1X,QoS,IPv6,Bonjour
Security:	User Authentication, Watermark, IP address filtering, anonymous access
System Compatibility:	ONVIF, PSIA, CGI, ISAPI

Interface

Audio Input:	1-ch 3.5 mm audio interface, MIC IN/LINE IN
Audio Output:	1-ch 3.5mm audio interface (line level, 600 Ω)
Communication Interface:	1 RJ45 10M/100M Ethernet interface/1 RS232
Alarm Input:	1
Alarm Output:	1
Video Input:	1 RJ12 interface
On-board storage:	Built-in Micro SD/SDHC/SDXC card slot, up to 64 GB

General

Operating Conditions:	-30 °C ~ 60 °C (-22 °F ~ 140 °F) Humidity 95% or less (non-condensing)
Power Supply:	12 VDC ± 10%, PoE (802.3af)
Power Consumption:	Max. 6.5 W
Dimensions:	78×105×32mm
Weight:	450g
NOTE::	-10: Cylindrical sensor unit -20: L-shaped sensor unit * Different brackets included for each sensor unit.
