China off Road Bus

China off Road Bus thumbnail-1
China off Road Bus photo-1
Negotiable MOQ: 1 Unit (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Type:
Other, off road bus
Fuel:
Diesel
Gear Box:
Manual
Contact Supplier Request Quote Chat Now
Dongfeng Special Vehicle (Shiyan) Bus Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Type Other, off road bus
Fuel Diesel
Gear Box Manual
Made In China
Steering Left
Drive RWD
Brand Name dongfeng brand
Place of Origin Hebei, China
Model EQ6670PT

Specifications

Perfect combination with military chassis and off road bus body;
High power and reliable performance;
Good gradeability

   S P E C I F I C A T I O N
EQ6670PT
Overall DimensionsLength(L×W×H):6700×2320×2750,2960(mm,With A.C)
ENGINE CHASSIS DIMENSIONS(mm)
Model : ISDe140 30 Wheel base : 3650
Type : Vertical,in-line,water-cooled,4 stroke,electronic control,direct injection,Euro-Ⅲ Chssis Model : EQ6640KST
No. of Cylinders : 4 Track front : 1774
Displacement(ml) : 4500(ml) Track Rear : 1774
Rated Output : 103(kw) WEIGHTS(Kg)
Max.Torque : 500(N.m) G.V.W (kg) : 6500
CLUTCH
Type : Single plate dry friction Curb weight (kg) : 5000
Outside diameter of : 350mm
of clutch lining :   Max. Speed : 80(km/h)
GEAR BOX
Model : 17TQ2-0030,Manual operation MAIN ASSEMBLY OF BODAY
No. of gears : 5 Forward and 1 Reverse
Body structure                 : Integral pressurized molding body,wider bus body
FRONT AXLE : Dongfeng across-country axle
REAR AXLE : Dongfeng across-country axle Interior trimming : Molding common interior trimming(grey)
Driver type : 4×4
Ratio : 6.17 Door&door pump           : Pneumatic folding middle door,driver door (1+1)
STEERING Window&glass                 : Standard
  : M5 Recirculating ball type steering
      Safety scuttle : One large (700*500mm)
FRAME Luggage compartment : Rear luggage compartment
    Ladder type frame with rivetted/bolted cross members.Side members are of channel section
    Air condition : Optional
SUSPENSION Video system                   : AM/FM Cassette recorder, (Optional:15/17′LCD,MP4)
Type : Leaf spring
No. of leaf spring : Front:10 Rear:10 Rain wiper : Bi-direction rain wiper
Rear reflecting mirror   : Manual operation rabbit-ear-type mirror
BRAKES
Service brakes : Dual circuit full air brake Inner mirror : Standard
Parking brake : Spring actuated parking brake acting on rear wheels Car-reversing radar       : Optional

Engine exhaust brake           Seat capacity                 : 3-19
: Coupled with service brake.
TYRES Seats : General seat
Tyres Standard : 11R18 Painting : Domestic paint
Optional : Not Others : Power Steering,Air brake, Clutch booster,   Desiccator,Fan, Small sun-visor curtain, Plat floor (PVC floor).
No. of wheels : Front:2 Rear:2 Spare:1
FUEL TANK
Capacity : Main:150 litres,Secondary:60 litres
ELECTRICAL SYSTEM Remarks:
System voltage : 24 Volts The specifications are subject to change with notice.These are indicative specifications for reference only.
Battery : 12V,70Ah capacity
Alternator Capacity : 70A
Wind screen wiper : 100W-2 Speed and intermittent wipe For further details,please contract dongfeng or your nearest dongfeng bus dealers.
Wind screen washer : Electrically operated.



China off road busChina off road busChina off road busChina off road bus
