6-7m City Bus Dongfeng Mini Bus

Dimensions

Overall Length

5990mm

Overall Width

2250mm

Overall Height

2990mm

Wheelbase

3300mm

Front Overhang

1860mm

Rear Overhang

860mm

Interior Height

1830mm

First Step Height

400mm

Gross Vehicle Weight

5990kg

Seats Capacity

10-29/10-23

Max Speed

95km/h

Engine

Engine Model

YC4F115-30

Engine Type

in-line, 4cylinders, 4-stroke

turbocharged, water-cooled

Position/Fuel

Front/diesel

Max Output

85kw

Max Torque

300N.m

Displacement

2659ml

Emission Standard

Euro III

Chassis

Chassis Model

EQ6570k3AC

Gear Box

Yiyang Power of Transmission 535 series

Clutch

Single plate, dry friction, helical spring, clutch booster

Front Axle

DFAC (2.3T)

Rear Axles

DFAC (4.2T)

Suspension

Leaf spring : front 8 rear 10 ; Shock absorber: DF ZF

Steering

Mechanical type

Brake

Dual circuit full air brake

Fuel Tank

90L

Tyres

7.00-16

Battery/Generator

6-QW-105/55A. 35A

Body

Body Type

Semi-integral body construction
Integral body construction

Interior Trimming

AC interior trimming

Side Window

upper fixed and bottom slding sash, light green

windscreen

Front : laminated glass; Rear : toughened glass

Defroster

Defroster with changeable power 24V,130W

Windscreen Wiper

opposed electric wiper system

Door

Front and middle pneumatic folding door

Rearview system

Manual rearview mirror

Others

common bus seats; domestic brand painting

GPS System, vehicle travelling data recorder (95km/h)

Side driver window sun visor; water dispense

Whole front window rolled sun visor

PVC floor covering; Two 700A skylight; air horn

Safety & Performance

Standard
Flat floor; Front and rear combination lamp
Dongfeng Pannico top-mounted A/C  12KW PN32 compressor
Half rolled sun visor; Driver's sun visor
High brake lamp; Side window curtain; wheel cover
Safety belt equipped with every seat
Emergency switch
2 safety hammer, 1kg fire extinguisher
Optional
High and low floor; sillica sand floor covering; alluminium checkered plate; iron checkered floor; iron wood floor
Foldable side window curtain; aeration Skylight; 4kg fire extinguisher;
Electronic bus-stop annunciator onboard motorcoach
Interior vehicle CCTV, corridor carpet

Entertainment Systems & Digital Amenities

Standard
MP3 radio system
Electric clock with temperature display
New front and rear combination lamp
Optional
MP4/MP5 video system; (15''/17'' inch color dispaly screen)
SD card, USB flash disk
Swing-in door remote switch controller
7-inch color screen reversing rearview monitoring system
