Help CenterChina Medium Size Universal Rotary Head Milling Machine UM1480A Table Size 2000x360mm
Related Products
-
China Manufacturer Universal Rotary Head Milling Machine UM1480A With Big Worktable SizeUS$ 15,440 - 17,600MOQ: 1 Set -
High Quality Medium Size Universal Rotary Head Milling Machine UM1480A From ChinaUS$ 15,440 - 17,600MOQ: 1 Set
-
Horizontal and Vertical Milling Machine With Milling Table Size 360x1600mmNegotiableMOQ: 1 Set
-
China Manufacturer Swivel Head Universal Milling Machine With Spindle Taper ISO50NegotiableMOQ: 1 Set
-
X6432B Keyway Milling Machine Tool With Table Size 1600x320mmNegotiableMOQ: 1 Set
The Specification of Universal Swivel Head Milling Machine(UM1480A):
Model |
UM1480A |
Spindle Taper |
ISO 50 |
Distance from Spindle to Column surface |
200-1000mm |
Distance from Spindle Nose to Table Surface |
210-700mm |
Max.Distance from Spindle Center to Table Surface(H) |
470mm |
Distance from Spindle Center to Table Surface |
280-1160mm |
Spindle Speed Range |
50-1500rpm |
Table Size |
2000×360mm |
Worktable Swivel Angle |
45° |
Table Travel |
1600mm |
Cross |
400mm |
Vertical |
500mm |
X,Y axis Feeding |
22.4-560mm/min |
Z axis Feeding |
11.2-280mm/min |
T-slots of Table |
3 |
Width |
18mm |
Distance |
80mm |
Main Motor |
5.5kw |
Feeding Motor |
3kw |
Coolant Pump Motor |
40w |
Overall Dimensions |
2300×2700×2300mm |
Weight |
3980kgs |
STANDARD ACCESSORIES:
l Halogen Lamp
l 3-Axis Digital Readout
l Power Feeds
l Horizontal Arbor Support
l Collet Chuck
l Drawbar
l Coolant System
l Machine Vice
l Manual and Parts List
OPTIONAL ACCESSORIES:
l Rotary Table
l Clamp Kit
l Universal Dividing Head
l Slotting Head
l End Mill Arbors
l Drill Chuck and Arbor
l Boring Head
l Angle Plates
FEATURES:
l 3 Axis Power Feed
l Long 2000mm Table
l Pendant Control with Integrated DRO(not visible on picture)
l Horizontal Milling Spindle
