Home > Manufacturing & Processing Machinery > Machine Tools > Punching Machine > WC67Y Series Hydraulic Press Brake

WC67Y Series Hydraulic Press Brake

WC67Y Series Hydraulic Press Brake thumbnail-1
WC67Y Series Hydraulic Press Brake photo-1
US$ 8,500 - 25,500 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
CNC or Not:
Normal
Power Source:
Other, Hydraulic, Hydraulic
Contact Supplier Request Quote Chat Now
Tengzhou Hising Machine Tools Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
QINGDAO
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
CNC or Not Normal
Power Source Other, Hydraulic, Hydraulic
Place of Origin Shandong, China
Brand Name TZHISING
Model Number WC67Y-20/1320-WC67Y-400/4000
Voltage 380V/220V Optional
Power(W) 4KW
Weight 1800kg
Dimension(L*W*H) 1700x1600x2100mm
Certification ISO9001:2008
Warranty 12 Months
After-sales Service Provided Engineers available to service machinery overseas

WC67Y Series Hydraulic Press Brake : for the specification and the detailed information of the product, pls see the photo.



Model nominal pressure(kn) length of working table(mm) distance between two colums(mm) throat depth(mm) travel distance of back-gauge(mm) stroke of the ram(mm) stroke adjustment of the ram(mm) stroke number(time/min) max.open height(mm) oil tank vol motor power (kw) Net weight Gross weight dimensions(mm)L*W*H
WC67K-20/1320 200 1320 1005 200 400 80 70 10 245 80L 4 1.5 1.8 1700*1600*2100
WC67K-30/1320 200 1320 1005 200 400 80 70 10 245 80L 4 1.5 1.8 1700*1600*2100
WC67K-40/1320 400 1320 1005 250 600 100 80 10 340 85L 4 2 2.5 1700*1600*2100
WC67K-63/2500 630 2500 2050 250 600 100 80 8 335 280L 5.5 5 5.5 3000*1700*2350
WC67K-80/2500 800 2500 2050 250 600 100 80 8 355 280L 7.5 6.5 7 3000*1700*2350
WC67K-80/3200 800 3200 2700 250 600 100 120 8 355 300L 7.5 7.5 8 3900*1700*2450
WC67K-100/2500 1000 2500 2050 320 600 150 120 8 415 280L 7.5 7.5 8 3100*1800*2560
WC67K-100/3200 1000 3200 2650 320 600 150 120 8 415 300L 7.5 8.5 9 3900*1800*2560
WC67K-100/4000 1000 4000 3150 320 600 150 120 5 415 370L 7.5 9 10 4500*1800*2580
WC67K-125/3200 1250 3200 3650 320 600 150 120 8 415 550L 7.5 8.5 9 3900*1900*2580
WC67K-125/3600 1250 3600 2850 320 600 150 120 8 415 300L 7.5 8.8 10.5 3950*1900*2580
WC67K-125/4000 1250 4000 3150 320 600 150 120 8 415 370L 7.5 9 10.5 4700*1900*2580
WC67K-140/4000 1400 4000 3150 320 600 150 120 8 415 370L 11 10 11.5 4700*2250*2580
WC67K-160/3200 1600 3200 2600 320 600 200 160 8 455   11 11 12 4100*1800*2650
WC67K-160/4000 1600 4000 3150 320 600 200 160 8 455   11 13 14 4800*1900*2700
WC67K-200/3200 2000 3200 2600 320 600 200 160 8 455   15 11.5 12.5 4200*2000*2750
WC67K-200/4000 2000 4000 3150 320 600 200 160 8 455   15 15 16 4800*2000*2750
WC67K-250/4000 2500 4000 3150 400 600 250 200 8 660   15 17 18 4800*2000*2750
WC67K-400/4000 4000 4000 3280 400 600 250 200 6 735   37 35 36 5000*2700*4000
