Help CenterDistributor Wanted Solid Wood , Mdf, Plywood ,plastic Cutting Machine
Related Products
-
Cnc Cutting Router Techno 1325K Cnc Router Woodworking for SaleUS$ 10,000 - 12,000MOQ: 1 Set -
Wholesaler Wanted Wooden Main Door Design Mdf Cutting MachineUS$ 11,000 - 15,000MOQ: 1 Set
-
Wood Cnc Router Made in China HS1325k Woodworking Combined Machine/cnc Carving Woodworking MachineUS$ 10,000 - 15,000MOQ: 1 Set
-
Manufacturer Directly Supply Router Cnc Wood Cutting Machine, Furniture Cnc Router, Woodworking Cnc Router 1325KUS$ 10,000 - 12,000MOQ: 1 Set
-
Automatic 3d Wood Carving Cnc Router HS1325k Automatic Brooom Heads Brush Making Cnc Machine Hobby Cnc Wood RouterUS$ 10,000 - 15,000MOQ: 1 Set
Before cooperate with Jinan Hanshi CNC Technology, don't tell you know who is the real professional cnc router cooperator! ;)
1, with intelligent, humanization and high automatic operation, this machine can make the operator much more easier for handling all. Any people can learn in one to three hours for operation, can save cost of labors.
2, with automatic nesting software, just input material’s size, computer can automatically nesting, generate G code. It can save time, with high utilization rate of plate and zero error.
3, double layer vacuum table can hold small pieces for excellent cutting, realize all kinds of customaries cabinet.
pplication Industry:
Application
Wardrobe cabinet, cupboard cabinets, computer tables, furniture, office furniture, wooden sound box, wooden furniture, kitchenware and other flat material, the milling type, edge down, drilling, engraving and other ancillary processing.
Performance Parameter:
Parameter |
HS1325K |
X,Y,Z,B Travelling |
1300*2500*200mm |
Table |
Double Layer Vacuum Table |
Frame |
Welded Structure |
X,Y,Z Drive System |
X,Y Helical rack and pinion, Z Ball screw |
Max Rapid |
30000mm/min |
Max Working Speed |
15000mm/min |
Spindle Power |
6.0KW |
Spindle Speed |
0-18000RPM |
Driving System |
Stepper System |
Working Voltage |
AC380V, 50/60 Hz, 3Ph |
Command Language |
G code |
Operating System |
NC studio |
Software |
Type 3,Artcame, UG |
Gross Weight |
1800KG |
Options |
Servo Motors |
1, to improve the utilization of the plate, open with a cutter, turned in any direction can be cut shaped, pushing saw in the end the material , with self-developed software automatically optimizes the average per plate.
2, save labor, one person can operate several machines (limited to automatic loading and unloading machines).
3, reduce labor intensity.
4, improved cutting speed ,saved the time human spent on board Proton move
5, reduced dust .
6. The automatic loading and unloading is fully automated, it is an optional function.
the machine can break of manual processing, greatly reducing the labor intensity.
7. This machine is fool-operation, all calculated to computer calculations, zero errors and zero failure rate. Simple operation, any unskilled laborer, factory-trained 3-5 hours can be directly posts.
wooden box or as your requirement
10 workdays after confirmed payment
The service of our cnc router machines:
1. 12 months guarantee for our machines except HSD spindle with 6 months.
2. 24 hours technical support by emails, fax or calling.
3. Free training in our factory. Also we can dispatch our technician to customers' place if customer
agrees to air ticket, food and hotel.
Jinan Hanshi CNC Technology Co., Ltd is a production enterprise which combines research & development, manufacturing and sales. The company specialized in Engraving Machine,Carpentry Engraving Machine,Furniture Engraving Machine,Advertising Engraving Machine,Laser Engraving Machine,Stone Engraving Machine,Glass Engraving Machine,Metal Engraving Machine etc. The team offers technical services computer,CNC machine and industrial automatic products relied on advanced technology and accumulated market experience.
Mainly products: CNC Engraving Machine(Carpentry Engraving Machine,Advertising Engraving Machine,CNC Machining Center,Stone Engraving Machine,Metal Engraving Machine ,Glass Engraving Machine, Furniture Relief Engraving Machine) Laser Engraving Machine(Laser seal machines, laser engraving machines, laser cutting machine, laser wood-block engraving machine),Computer carving series (plotter, banner machine, pictorial machine, inkjet machine, acrylic plastic machine), etc.
“Making high quality products, creating world brand” as our development concept. “To create maximum value for customers” as our business principle. We hope to cooperate with more customers for mutual development and benefits.
Jinan Hanshi CNC factory and workshop pictures
In order to help you choose the best suitable machine, please try to reply my questions below, thanks.
How to buy?
Payment terms:
Q1: What about your material, wood or acrylic or?
Q2: The size of your mateiral, length? Width and thickness?
Q3: Do you want to cut or engrave your material? Or both cut & engrave?
Q4: What machining effection do you want to get? It is better you can send sample pictures to me .
Q5: The machine chooses 220v or 110v or?
Q6: What about your nearest sea port?
*-*Any colors, any logo acceptable, leave an inquiry to know more about Price, Packing, Shipping and Discount.
