12" Bicycle Electric / TDU12Z001

Name: 12" Bicycle Electric / TDU12Z001
Brand: ENDA
SKU: 122076525
Availability: InStock

Negotiable MOQ: 212 Pieces (Price negotiable depending on order volume and customization)

Key Specifications

Wattage:

< 200w

Voltage:

24V

Power Supply:

Lithium Battery

Zhejiang Enze Vehicle Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

ningbo

Delivery Detail:

Delivery time depends on order quantity.

Voltage 24V

Power Supply Lithium Battery

Wheel Size Other, 12”

Motor Brushless

Certification Other, CE & EN15194 approval

Frame Material Aluminum Alloy

Foldable Yes

Max Speed Other, <30km/h

Range per Power 31 - 60 km

Place of Origin Zhejiang, China

Brand Name ENDA

Model Number TDU12Z001

Specifications

1. 12" bicycle electric/ TDU12Z001
2. Alloy frame
3. Lithium battery
4. Easy handy
5.CE, EN15194,GS, ROHS

12" bicycle electric / TDU12Z001
Performance
Max Speed:	25 km/h
Range:	>30 kms
Climbing Degree:	≤8 degrees
Run Mode:	Pedalling Assist Mode or Throttle Mode
Recharging Time:	6-8 hours
Charge Cycle Times:	>500 times
Load Capacity:	100 kgs

Electric Assist System
Sensor	LiShui, ES-02,1:1 intelligent Speed Sensor when switch off throttle
Motor	Rear, 24V/180 Watt, Brushless
Controller	LiShui, EZ-02, 24V/180W, EN-15194 approval
Battery	Phylion, Lithium-ion 24V/10Ah
Charger:	SanShi, Li-ion battery charger, CE approval

Features
Frame:	12" P type Aluminium Folding E-bike, Single speed, TIG welded W/battery bracket, patented Alloy Latch system
Fork:	Aluminium, Straight blade w/ pivot
Handlepost:	Integrated folding adjustable handlepost w / patent hinge
Wheels:	Alloy Front and Rear Integrated wheel
Brake:	Front/ V brake; Rear/ Band Brake
N.W:	18.5 kgs
