IP65 19inch server rack price
- 10000 Set / Sets per Month
- shenzhen
- T/T L/C D/P D/A Credit Card
- 30A automatic transfer switch
- Hot selling rack cabinet weatherproof/SK-235M waterproof telecom outdoor cabinets with fan
- Hot selling rack cabinet weatherproof/SK-291 outdoor telecom cabinet rack
- Hot selling rack cabinet weatherproof/SK-345 outdoor waterproof cabinet
- Hot selling rack cabinet weatherproof/ SK-400B fan type ip54 battery cabinet
- Hot selling rack cabinet weatherproof/SK-235M waterproof outdoor racks with fan
Product Details
Place of Origin: | Guangdong, China | Brand Name: | KTMP | Model Number: | KTMP-SF-23 |
Protection Level: | IP65 | Type: | Distribution Box | External Size: | Optional |
Product Description
IP65 19inch server rack price
Model: KTMP-SF-23
Specification :
Model | 600x600mm,600x800mm,600x1000 |
Capacity | 22U,27U,32U,37U,42U,47U |
Standard | Comply with ANS/EIA RS-310-D,IEC297-2,DIN4149,PART1,DIN41491 Standard; |
IP grade | IP20 |
Color | RAL9004, RAL9005, RAL7035 etc |
Thickness: | mounting profile: 2.0mm,mounting angle:1.5mm others: 1.2mm |
Material: | Nine-folded profiled(SPCC) |
Static Loading Capacity: | 1000Kgs |
Packing | assembled: plastic bag, then covering corrugated case,wooden case for optional |
Surface finish: | Degreasing, Pickling, Phosphating, Powder coated |
Door | vented Hexagonal mesh |
Features :
1.The frame is made of nine or fourteen folds structure and welded by special 3-Tees.The whole configuration is firmed and the static load is 1000Kgs.
2.High density vented single front door and double section rear door make the vented area no less than 65% of the door area, the exquisite appearance. The front door can choose international fashion color of tempered glass.
3.The side door can be installed and uninstalled quickly which make the working conveniently.
4.The cabinet can be installed castors and adjustable feet at one time which make the moving and fixing easy.
5.The door hinge is interchangeable, top cable entry hole with rubber cover.
6.The depth is adjustable(take 25MM as unit),the height of capacity is adjustable(take 1U as unit).
7.Optional accessories.
8.We can manufacture the cabinet according to the customer special requirements also.
9.8 heights-12U,17U,22U,27U,32U,37U,42U,47U.
10.3 depth options-600,800 and 1000mm.
11.Flexible packing methods allows for convenient stocking and end user delivery.
12.Multiple sizes available.
13.Customization requests welcome.
Details Show :
Main Parts :
No. | Name | QTY | Material | Remarks | |
600w | 800w | ||||
1 | Frame | 1 | 1 | SPCCT=1.5 | 9 folds profiled bracket |
2 | Front door | 1 | 1 | SPCCT=1.2 | Flat door with vented holes , optional |
3 | Front door lock | 1 | 1 | —— | MS831/optional |
4 | Left rear door | 1 | 1 | SPCCT=1.2 | Flat door with vented holes , optional |
5 | Rear door lock | 1 | 1 | —— | M818/optional |
6 | Right rear door | 1 | 1 | SPCCT=1.2 | Flat door with vented holes , optional |
7 | Top cover | 1 | 1 | SPCCT=1.2 | Fan tray is available |
8 | Side Panel | 2 | 2 | SPCCT=1.2 |
|
9 | Castor setup panel | 2 | 2 | SPCCT=2.0 |
|
10 | Castor | 4 | 4 | —— |
|
11 | Support feet | 4 | 4 | —— | M12 |
12 | Mounting beam | 4/2 | 12/8 | SPCCT=1.5 | Below 27U(include 27U):2pcs, 800w cabinet:12pcs |
13 | Mounting profile | 4 | 4 | SPCCT=2.0 |
|
14 | Spacer | no | 12/8 | SPCCT=2.0 | Only for 800W cabinet / Below 27U(include 27U):8pcs |
15 | Cable management holder with cover | no | 2 | SPCCT=1.2 | Only for 800W cabinets |
16 | Bottom panel | 1 | 1 | —— | Optional accessories |
Advantage :
1.Secure,firm and reliable
2. Easy to maintain equipment
3. Two Packing Ways:
1).Assembly packing to save labour cost, ready to resell or use
2).Disassembly packing to save space and transport cost, easy to assemble
4.Certification: ISO 9001:2000
5. OEM/ODM service available
Other Series :
Company Introduction :
Shenzhen KTMP Technology Company Limited is a professional sheet metal products
manufacturer . As a skilled manufacturer in sheet metal processing industry for 12 years , KTMP is a
company with the whole line of designing , producing , selling and trading a standard series of
products while continually making strides in new product development . Welcome to OEM all kinds of
network/ server cabinets .
Certification :
FAQ :
Your satisfaction is our greatest feedback.
Q1:If OEM available?
A:Yes, we provide all of our products OEM.
Q2:What are your company normal payment?
A:We accept L/C; T/T; D/P; D/A; Western Union;
Q3: What are your company normal export terms?
A:We normally export with DHL EMS FedEX UPS and so on.
Q4:Is sample available?
A:Sample is available.
