19 inch standard 32u network open rack
Model: KTMP-NF-18
Specifications:
Size | 600 x 800 |
Capacity | 18U-47U |
Material | SPCC Cold rold steel |
Thickness | Mounting profile 2.0mm Mounting angle 1.5mm Others 1.2mm |
Standard | Complies with ANSI/EIA RS-31O-D, IEC297-2, DIN41491: PART1, DIN41494: PART7,GB/T3047.2-92, ETSI Standard |
Color | Optional: Black(RAL9004) White(RAL7035) Grey(RAL7032) |
Protection Degree | IP20 |
Surface Finish | Degreasing, Pickling, Phosphating, Powder coating |
Loading Capacity | 800kg |
Door | Flat mesh front door |
Features :
* New design for the front door metal panel,more and more popular in cabling market.
* Reliable structure, static loading capacity:600-800KG(Optional castors and plinth)
* Adjustable feet and castors are available, moving conveniently, and fixing reliablity.
* Baying together easy, quickly efficiently and firmly.
* Bule or green decoration beading for the glass door looks more attractive.
* International popular tempered glass front door with new metal panel design,solid steel rear door or single perforated door or double perforated doors.
* Flat package will save more space and freight cost,we will supply assembling manual,assembling easily.
* Optional cable entry on top cover and bottom panel, removable Front & rear door and side panel facility, ventilation and rat-proof on the bottom.
* Varies optional accessories, reliable quality.
* Optional opening hole and varies specification upon customers' special requirements.
* 8 heights - 12U, 18U, 22U, 27U, 32U, 37U, 42U, 47U
* 3 depth options - 600, 800 and 1000 mm
* Flexible packing methods allows for convenient stocking and end user delivery.
* Multiple sizes available.
* Customization requests welcome
Packing :
Picture Show :
Optional Front Doors:
.tempered glass with slot door border
.tempered glass with vented door border
.arc shaped vented door
.high-density vented door
.steel door without holes
Optional Rear Door:
.vented door with hexagonal holes
.high-density vented door-dual open
.steel door without holes
Main parts :
No. | Component Name | Quantity | Unit | Material | Surface Finish | Remark |
1 | Top Cover | 1 | pc | SPCC cold rolled steel T1.0 | Powder Coated | --- |
2 | Fan unit | 2 | pc | --- | Powder Coated | with 2 fans |
3 | Mounting profile | 4 | pc | SPCC cold rolled steel T1.5 | Powder Coated | --- |
4 | Mounting angle | 6 | pc | SPCC cold rolled steel T1.2 | Powder Coated | 4pcs for lower 30U |
5 | Shelf | 2 | pc | SPCC cold rolled steel T1.2 | Powder Coated | 1 pc for lower 20U |
6 | Spring lock | 1 | pc | --- | Black | --- |
7 | Toughened glass front door | 1 | pc | Tempered glass/ SPCC T1.2 | Powder Coated | --- |
8 | Frame | 1 | pc | SPCC cold rolled steel T1.0 | Powder Coated | --- |
9 | Side Panel | 2 | pc | SPCC cold rolled steel T1.0 | Powder Coated | Removable steel door |
10 | Bottom Panel | 1 | pc | SPCC cold rolled steel T1.0 | Powder Coated | --- |
11 | Small round lock | 1 | pc | --- | Nickel Coated | --- |
12 | Steel rear door | 1 | pc | SPCC cold rolled steel T1.0 | Powder Coated | --- |
13 | M6 B-head screw | 20 | pc | Steel | Color Zinc Coated | 40pcs for over 30U |
14 | M6 square nut | 20 | pc | Steel | Color Zinc Coated | 40pcs for over 30U |
15 | 2 heavy duty castor | 4 | pc | SPCC cold rolled steel T1.0 | Powder Coated | --- |
16 | M12 adjustable feet | 4 | pc | SPCC cold rolled steel T1.0 | Powder Coated | --- |
Remark: we mainly produce the customized sheet metal parts, all the products display here are to
show our business scope only. Thanks!
Advantages :
1. Rich experience on manufacture sheet metal industry
2. High quality material , exquisite design in every details
3. Secure , firm and reliable , Easy to maintain equipment
4. Two packing ways :
(1) Assembly packing to save labour cost , ready to resell or use
(2) Disassembly packing to save space and transport cost , easy to assemble
5. OEM/ODM service available
Other Series :
Company Introduction :
Shenzhen KTMP Technology Company Limited is a professional sheet metal products
manufacturer . As a skilled manufacturer in sheet metal processing industry for 12 years , KTMP is a
company with the whole line of designing , producing , selling and trading a standard series of
products while continually making strides in new product development . Welcome to OEM all kinds of
network/ server cabinets .
