Help CenterGood Quality Network Cabinet Metal Enclosure
Related Products
good quality network cabinet metal enclosure
Model: KTMP-NF-20
Features :
Exquisite design with precise craftsmanship;
Welded steel frame for front and back part, which can be flat packing, easy to transfer;
Tempered glass front door with over 180 turning degree; arc shaped vented front door border;
Steel rear door with square holes, little round lock, optional other lock;
Removable side panel wit latch, easy to install(optional lock);
Adjustable feet and castors are available simultaneously:
Cable entry on the top, adjustable cable entrance at the bottom with panel:
Advanced handle locks for front door, optional other lock;
S-shaped mounting profile, free to move forward and back;
Efficient baying kit of cabinet, earthing kit:
Optional plinth to fix cabinet on floor; under base cable entry:
Various optional Accessories for common using:
Unassembled packing, about 2/5 of original volume, save container space;
Picture Show :
Optional Front Doors:
.tempered glass with slot door border
.tempered glass with vented door border
.arc shaped vented door
.high-density vented door
.steel door without holes
Optional Rear Door:
.vented door with hexagonal holes
.high-density vented door-dual open
.steel door without holes
Size : 600x600 ; 600x800 ;
Capacity : 18U -47U
Main Parts :
No. |
Component Name |
Quantity |
Unit |
Material |
Surface Finish |
Remark |
1 |
Top Cover |
1 |
pc |
SPCC cold rolled steel T1.0 |
Powder Coated |
--- |
2 |
Fan unit |
2 |
pc |
--- |
Powder Coated |
with 2 fans |
3 |
Mounting profile |
4 |
pc |
SPCC cold rolled steel T1.5 |
Powder Coated |
--- |
4 |
Mounting angle |
6 |
pc |
SPCC cold rolled steel T1.2 |
Powder Coated |
4pcs for lower 30U |
5 |
Shelf |
2 |
pc |
SPCC cold rolled steel T1.2 |
Powder Coated |
1 pc for lower 20U |
6 |
Spring lock |
1 |
pc |
--- |
Black |
--- |
7 |
Toughened glass front door |
1 |
pc |
Tempered glass/ SPCC T1.2 |
Powder Coated |
--- |
8 |
Frame |
1 |
pc |
SPCC cold rolled steel T1.0 |
Powder Coated |
--- |
9 |
Side Panel |
2 |
pc |
SPCC cold rolled steel T1.0 |
Powder Coated |
Removable steel door |
10 |
Bottom Panel |
1 |
pc |
SPCC cold rolled steel T1.0 |
Powder Coated |
--- |
11 |
Small round lock |
1 |
pc |
--- |
Nickel Coated |
--- |
12 |
Steel rear door |
1 |
pc |
SPCC cold rolled steel T1.0 |
Powder Coated |
--- |
13 |
M6 B-head screw |
20 |
pc |
Steel |
Color Zinc Coated |
40pcs for over 30U |
14 |
M6 square nut |
20 |
pc |
Steel |
Color Zinc Coated |
40pcs for over 30U |
15 |
2 heavy duty castor |
4 |
pc |
SPCC cold rolled steel T1.0 |
Powder Coated |
--- |
16 |
M12 adjustable feet |
4 |
pc |
SPCC cold rolled steel T1.0 |
Powder Coated |
--- |
Remark: we mainly produce the customized sheet metal parts, all the products display here are to show our business scope only. Thanks!
Advantage :
1. Rich experience on manufacture sheet metal industry
2. High quality material , exquisite design in every details
3. Secure , firm and reliable , Easy to maintain equipment
4. Two packing ways :
(1) Assembly packing to save labour cost , ready to resell or use
(2) Disassembly packing to save space and transport cost , easy to assemble
5. OEM/ODM service available
More Products :
Company Introduction :
Shenzhen KTMP Technology Company Limited is a professional sheet metal products
manufacturer . As a skilled manufacturer in sheet metal processing industry for 12 years , KTMP is a
company with the whole line of designing , producing , selling and trading a standard series of
products while continually making strides in new product development . Welcome to OEM all kinds of
network/ server cabinets .
