Specifications
1) for coal, charcoal, gypsum, sponge iron.2) hydraulic system.
WORKING PRINCIPLE
This series of Briquette Ball Press will pass the power on to the two pressure roller through the reducer.The two sides and roll rotation, in both the rotating roll,Natural materials to enter the ball roll mode, with the roll rotation, material pressure on a small become larger, When the material to the two rollers rotating line contact point, the pressure of materials has reached the peak. Tremendous pressure in the role of line, the materials become a finished product from the powder ball.
Application materials:
A: Coal/coke/charcoal powder.
B: Metal powder: Iron powder, magnesium oxide powder, copper powder, chromium ore, lead, zinc scrap, bauxite, nonferrous metal powder, silicon manganese alloy powder etc.
C. Mineral powder: aluminum powder, toner, gypsum, sludge, desulphurization gypsum powder etc
Technical parameters
Model |
Roll diameter(mm) |
Capacity(t/h) |
Power(kw) |
YKBM290 |
290 |
1-3 |
5.5 |
YKBM360 |
360 |
4-6 |
11/15 |
YKBM430 |
430 |
6-8 |
18.5 |
YKBM500 |
500 |
8-12 |
18.5/37/55 |
YKBM500-3 |
500 |
5-8 |
37 |
YKBM500-4 |
500 |
8-12 |
55 |
YKBM650 |
650 |
10-15 |
37/45 |
YKBM750 |
750 |
15-20 |
75/90/110 |
YKBM850 |
850 |
20-25 |
90/110 |
YKBM1000 |
1000 |
25-30 |
90/110/132 |
Advantages:
1) it produces different shape of briquettes by replacing matching moulds, shapes include square,round,triangle,etc.
2) Besides the normal products, special moulds can also be designed and manufactured according to the customers’ requirements.
Zhengzhou Sinoder Indutech Machinery Co., ltd (hereafter referred to as "Sinoder") is a joint-stock machinery manufacturing enterprise, integrating industrial scientific research, production and marketing. The company is located in the Industry Area Zone of Zhengzhou, China.
The main products cover industrial drying machines,industrial crushing machines, mineral processing machines, brick machines, biomass energetic machines, environment protection equipment, food oil press machines and other mechanical equipment. Our key product include stone crusher,sand maker, stone washing machine, ball mill, flotation cell, AAC block plant, rotaty drying machines, biomass burner, coal gasifier, oil press machine, packaging machine, breeding machines, fertilizer and pellets machine and other machines.
Sinoder offer not only products with good quality and competitive price, but also top service and solution.
Website:
If you want to know more information , Pls to contact us
Tel: 0371 55933391 Fax: 0371 55919082
1.Waterproof packing with the international export standard by 20ft, 40ft, 40hp container.
2. Equipment Fittings, Electric Motor and Power Cabinet will be packed in Wooden Case or Iron Box. Other Equipment will be packed by Color-Stripes Plastic Cloth.
3. Or as per customer's requirements.
1.Pre-sale services:
1) Selecting equipment type;
2) Designing and fabricating the products in accordance with the special requirements of the clients;
3) Training technical personnel for our clients;
4) Providing construction and technology consultations or working out proper construction schemes for those new, special or difficult projects.
2.Services provided during the sale:
Respect our clients; present the clients with ease, relaxation and a surprise; devote ourselves to improve the total value of our clients.
1) Checking products acceptance ahead of delivery;
2) Introducing the service system to our clients.
3. After-sale services:
Improve the added value of our products, and let the clients free from the using troubles:
1) Assisting the clients preparing for the first construction scheme;
2) Installing and testing the equipments;
3) Training the first-line operators on site;
4) Examining the equipment regularly;
5) Taking the initiatives to eliminate the failure(s) rapidly at site;
6) Distributing the guarantee fittings door-to-door;
7) Providing technical exchanging;
8) Providing maintenance for big item
