Help Center18000UE pv Inverter
Related Products
-
Grid Tie Inverter for Wind Turbine SUN-500G-WDLUS$ 1 - 200MOQ: 3 Pieces -
Grid Tie Inverter for Wind TurbineUS$ 1 - 200MOQ: 3 Pieces
-
Grid Tie Inverter for Wind Turbine 500G_WALUS$ 1 - 200MOQ: 3 Pieces
-
Grid Tie Inverter for Wind Turbine 1000G_WAUS$ 1 - 200MOQ: 10000 Pieces
-
Grid Tie Inverter for Wind Turbine 250G_WALUS$ 1 - 200MOQ: 3 Pieces
Specifications
1.DC input voltage of up to 1000 V2.Maximum efficiency of 98 %
3.Bluetooth technology
General Descriptions
> DC input voltage of up to 1000 V
> Maximum efficiency of 98 %
> Internal DC Switch
> Transformerless
> Compact design
> Muti MPP controller
> MTL-String
> Bluetooth Technology
> Easy installation
> Sound control
> Comprehensive Growatt warranty program
Europe ENS
> Simple national setting of line supply monitoring(ENS)
> Easy country configuration
> Muti-language display
> Currently available for Germany France UK Austria Switzerland Italy and Spain
Communications
> RS485 /RS232/GPRS interfaces
>Computer monitoring software
> Standards complied:VDE0126-1-1, IEC62109, RD 1663, G59, G83, EN61000-6-2, EN61000-6-3, AS4777, AS/NZS 3100, ENEL-Guide, VDE-AR-N4105, CEI 0-21
Technical Specifications
Model |
10000UE |
12000UE |
18000UE |
20000UE |
INPUTDATA | ||||
Max. DC Voltage |
10200W |
12250W |
18400W |
20000W |
MPP Voltage Range |
400V-800V |
400V-800V |
400V-800V |
400V-800V |
Max DC voltage |
1000V |
1000V |
1000V |
1000V |
Max. DC Power |
10.4kWp |
12.5kWp |
15.6kWp |
22kWp |
Max. Input Current |
15A/15A |
17A/17A |
23A/23A |
25A/25A |
Number of MPP Trackers/ |
2 |
2 |
2 |
2 |
Strings Per MPP Tracker |
2/2 |
2/2 |
3/3 |
3/3 |
DC connections |
MC4(optinal MC3) |
MC4(optinal MC3) |
MC4(optinal MC3) |
MC4(optinal MC3) |
OUTPUT (AC) | ||||
Rated Output Power |
10kW |
12kW |
18kW |
19.5kW |
Max. AC Output Current |
16A |
19A |
29A |
32A |
AC Voltage Range |
3/N/PE 230~400V |
3/N/PE 230~400V |
3/N/PE 230~400V |
3/N/PE 230~400V |
Rated Grid Frequency |
50Hz/60Hz |
50Hz/60Hz |
50Hz/60Hz |
50Hz/60Hz |
Output Current THD |
< 3% (at nominal power) |
|||
Power Factor |
0.8(lagging)~0.8(leading) |
|||
AC connection |
Three phase |
Three phase |
Three phase |
Three phase |
SYSTEM | ||||
Max. Efficiency |
98.00% |
98.00% |
98.00% |
98.00% |
Euro. Efficiency |
97.50% |
97.50% |
97.50% |
97.50% |
Protection Degree |
IP65(outdoor) |
IP65(outdoor) |
IP65(outdoor) |
IP65(outdoor) |
Power Consumption at Night |
0W |
0W |
0W |
0W |
Operating Temperature |
-25~+60°C |
-25~+60°C |
-25~+60°C |
-25~+60°C |
Cooling concept |
Fans |
|||
Ground failtrue detection |
yes |
|||
DISPLAY AND COMMUNICATIONS | ||||
Display |
LCD |
LCD |
LCD |
LCD |
Standard Comm. Interfaces |
RS485/RS232 |
RS485/RS232 |
RS485/RS232 |
RS485/RS232 |
Optional Comm. Interfaces |
GPRS/blue tooth |
|||
MECHANICAL DATA | ||||
Net Weight |
40kg |
40kg |
55kg |
55kg |
