Prefabricated steel structure warehouse
This kind of pre-fabricated steel structure house is a new type materials with characteristics such as light weight, high strength, and insulated.
Pre-fabricated steel structure house is mainly used for large-span structures, workshops, warehouses, office buildings, large supermarkets, shopping malls, sports stadiums, logistics warehouses, showrooms, hangar, etc.
Prominent advantage
1 Widely application: Construction site, office building, family living house, dormitory, canteen, recreation room, washing room, outdoor temporary building, etc.
2 Flexible layout: Doors,windows and indoor partition can be located at any position.
3 Environment friendly: Repeated use, no construction garbage caused.
4 Easy & quick install:6 Chinese worker can finish 300 m2prefab house in 2 days
5 Life span: Anti-rust and normally more than 10-15 years using
6 Economical: It is much cheaper than brick concrete house .
The Material available for choose:
No. |
Item |
Material |
specification |
1 |
Steel structure |
Square hollow section+ C section steel+ aluminum profile |
|
2 |
Floor (Available choice) |
Plywood |
1220x2440x15mm |
PVC flooring |
2000x1mm |
||
3 |
Wall (Available choice) |
EPS sandwich panel |
50mm/75mm 100mm/150mm
|
PU sandwich panel | |||
Rock wool sandwich panel | |||
4 |
Door (Available choice) |
Sandwich panel door |
800x2000mm |
Steel wooden door |
900x2000mm |
||
5 |
Window (Available choice) |
PVC sliding window |
1125x1000mm |
Aluminum window | |||
Shutter | |||
6 |
Roof (Available choice) |
EPS sandwich panel |
50mm/75mm 100mm/150mm
|
PU sandwich panel | |||
Rock wool sandwich panel | |||
Asphalt shingle | |||
Synthetic resin tile | |||
7 |
Ceiling (Available choice) |
Sandwich panel ceiling |
600x600mm |
Gypsum ceiling | |||
PVC ceiling |
Prefab K House ↑ Container House ↑ Modular T House ↑
Sentry Box↑ Prefab SHS Building↑ Light Steel Villa↑
Q 1: What are your main products?
A: Our man products have prefab K house, T house, SHS house, H house, container house, light steel structure villa, steel structure warehouse, sentry box, sandwich panel and other constructive materials.
Q2: What will client provide before factory offers good quotation?
A: When we receive inquiry from client, client please fills purchasing intention sheet, providing us with information of house dimensions, draft drawing, layout and materials for prefabricated house. We will design the drawings and offer competitive quotation with the above information.
Q3: What are main materials of prefabricated house?
A: Our prefabricated house materials mainly include light steel structure, sandwich panel, roof tile, door, window, covers, screws and other accessories.
Q4: How you calculate the total area?
A: Industry calculation rule as below:
- (1) house area = exterior house length X exterior house width X floor
- (2) canopy area=exterior house length X 1/2 X canopy width
- (3) staircase area = 4.5 sqm X quantity of staircase
- (4) corridor area = exterior house length X corridor width
- (5) total area = (1) + (2) + (3) + (4) + (5)
Q5: What drawing of house will factory supply?
A: Plan drawing, elevation drawing, sectional drawing, foundation drawing, installation drawing.
Q6:How many types of sandwich panel do you have?
A: We have EPS(polystyrene)sandwich panel, rock wool sandwich panel, and PU(polyurethane)sandwich panel.
The characteristics of your sandwich panels respectively:
- 1.EPS(polystyrene)sandwich panel: thickness is 50mm, 75mm, 100mm. EPS volume weight is 80-200Kg/m3, water-proof.
- 2.Rock wool sandwich panel: thickness is 50mm, 75mm, 100mm. Rock wool volume weight is 200-400Kg /m3, fire-proof, sound-insulation, heat-preservation.
- 3.PU(polyurethane)sandwich panel: thickness is 50mm, 75mm, 100mm. PU volume weight is 150-300/m3 water-proof, fire-proof, heat-proof, heat-insulation, heat-preservation, sound-insulation.
Q7: How many colors do your sandwich panels have?
A: Offwhite, ivory white, blue, green and red color.
Q8: What is the life expectancy of prefabricated house?
A:10-15years.
About Max Prefab
- Who we are?
We are an innovative company with great commitment, contribution heart, passion and responsibility.
- What we do?
We are specialized in designing, manufacturing andbuilding high quality environmental prefabricated house, steel structure warehouse, container house, mobilesteel villa, sentry boxes, porta cabins,portable toilets and so on.
- How we do?
Our main processing steps include accurate measuring, cutting, welding, de-oiling, grinding, polishing, rust cleaning, primer painting,surface painting and packing, each step of manufacture is under exact measurement and responsible working attitude to guaranteed our quality and client benefit.
Why US?
- Elite engineers,100% accuracy
- More than 100 mature product designs that are tested by market already
- Guarantee exclusive agency: One country One Exclusive Agent
- 4000sqm steel structure workshop,10000sqm sandwich panel production workshop
We are innovative and have been integrating the relevant green materials all the time for the complete turnkey solution
- We got a committed team who always care for you,customize design for you,report to you,and handling the troublesome cases for you.because you are the reason that we are here.
- Monthly production capacity:
- 20000sqm prefabricated hous
- 200 units of container house
- 4000sqm steel villas
- 30000sqm steel structure workshp
- 400 units of sentry boxes
8. We are sharing a long term cooperation and co-development vision with you!
We sign sole agency agreements and we are together as a whole! Wining is just a result of our friendship.
Welcome to Join us!
