Sony Effio-E Metal Housing Outdoor IR Varifocal Security Camera

Sony Effio-E Metal Housing Outdoor IR Varifocal Security Camera thumbnail-1
Sony Effio-E Metal Housing Outdoor IR Varifocal Security Camera thumbnail-2
Sony Effio-E Metal Housing Outdoor IR Varifocal Security Camera photo-1
Sony Effio-E Metal Housing Outdoor IR Varifocal Security Camera photo-2
Negotiable MOQ: 10 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
Kaansky
Model Number:
KST-F728
Contact Supplier Request Quote Chat Now
Shenzhen Kaansky Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name Kaansky
Model Number KST-F728
Type Analog Camera
Style Bullet Camera
Sensor CCD
Technology Infrared
Special Features Waterproof / Weatherproof

Specifications

security camera
Professional cctv camera manufacturer
CE,FCC,RoHS and ISO9001 certificate
Accept OEM order,
Fast deliver



Features:

1.IR Distance 35-40M

2.Adopting 42PCs f5mm IR Leds

3.Standard lens:2.8-12mm lens

4.Dual glass, no IR diffusion and fog

5.IP66, outdoor installation

6.Cable-managed Bracket: to prevent external force of destruction such as cutting

Model KST-F728-N60 KST-F728-K65 KST-F728-E65 KST-F728-EP70
Image Sensor 1/3" COLOR SONY
 Super HAD CCD		 1/3" COLOR SONY
 Super HAD CCD		 1/3" COLOR SONY
 EFFIO		 1/3" COLOR SONY
EFFIO-P
TV System PAY/NTSC
Image Resolution PAL:752(H)×582(V),
 NTSC:768(H)×494(V)		 PAL:976(H)×582(V),
 NTSC:976(H)×494(V)		 PAL:976(H)×582(V),
 NTSC:976(H)×494(V)		 PAL:976(H)×582(V),
 NTSC:976(H)×494(V)
Horizontal Resolution 600TVL 650 TVL 700 TVL 700TVL
CCD+DSP 639ccd+CP2040 639ccd+K9 673ccd+EFFIO4140 663ccd+EFFIO-P
Digital to Analog 9Bit
Minimum illuminator 0.1LUX/F1.2
S/N Ratio ≥48dB ≥58dB
AES 1/50-1/100,000sec(PAL),1/60-1/100,000sec(NTSC)
WDR D-WDR D-WDR D-WDR SUPPER WDR
DNR 2D-DNR 3D-DNR 2D-DNR 3D-DNR
OSD OSD OSD OSD OSD
White Balance ATW/Manual/Auto
AGC Auto/Manual/Off
BLC ON/OFF
Gamma Adjusting 0.45
synchronization System Internal Synchronization
Video Output 1.0Vp-p,75Ω
IR  5mm x 42pcs
IR Distance 30-40 Meter
LENS 2.8-12mm
Voltage DC12V (9V ~ 15V)
Operating Enviroment ~ / 10% ~ 95%RH
Weight 1.0kg/0.8kg
packing 210*105*122mm

 Sony Effio-E metal housing Outdoor IR Varifocal security CameraSony Effio-E metal housing Outdoor IR Varifocal security Camera

 Sony Effio-E metal housing Outdoor IR Varifocal security Camera

Sony Effio-E metal housing Outdoor IR Varifocal security CameraSony Effio-E metal housing Outdoor IR Varifocal security CameraSony Effio-E metal housing Outdoor IR Varifocal security CameraSony Effio-E metal housing Outdoor IR Varifocal security Camera

Sony Effio-E metal housing Outdoor IR Varifocal security Camera
