1/3'' Sony EFFIO 700 TVL Waterproof IR Camera

1/3'' Sony EFFIO 700 TVL Waterproof IR Camera thumbnail-1
1/3'' Sony EFFIO 700 TVL Waterproof IR Camera photo-1
US$ 10 - 50 MOQ: 50 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
Kaansky
Model Number:
KST-I505
Contact Supplier Request Quote Chat Now
Shenzhen Kaansky Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name Kaansky
Model Number KST-I505
Type Analog Camera
Style Bullet Camera
Sensor CCD
Technology Infrared
Special Features Waterproof / Weatherproof

Specifications

1. professional CCTV manufactory
2. Accept OEM order
3. IR Distance 15-20M
4. Adopting 24PCs 5mm IR Leds
5. CE, FCC, RoHS

 2012 new design 700 TVL waterproof  IR Camera


Models:KST-I504

Features:

1. IR Distance 15-20M
2. Adopting 24PCs 5mm IR Leds
3. Standard lens: 3.6mm lens;(2.8mm, 6mm optional)
4. Dual glass, no IR diffusion and fog
5. IP66, outdoor installation

6. Cable-managed Bracket: to prevent external force of destruction such as cutting








Model KST-I505-P442 KST-i505-N48 KST-I505-N60 KST-I505-E52 KST-I505-E65
Image Sensor 1/4" SHARP 1/3" COLOR SONY
Super HAD CCD		 1/3" COLOR SONY
Super HADCCD 		1/3" COLOR SONY
EFFIO		 1/3" COLOR SONY
EFFIO
TV System PAL/NTSC
Image Resolution PAL:500(H)×582(V),
NTSC:510(H)×492(V)		 PAL:752(H)×582(V),
NTSC:768(H)×494(V)		 PAL:752(H)×582(V),
NTSC:768(H)×494(V)		 PAL:752(H)×582(V),
NTSC:768(H)×494(V)		 PAL:976(H)×582(V),
NTSC:976(H)×494(V)
Horizontal Resolution 420TVL 480TVL 600TVL 520TVL 700TVL
CCD+DSP 633ccd+3142 633ccd+3172 639ccd+CP2040 633ccd+EFFIO4127 WDR K700
Digital to Analog 9Bit 10Bit 10Bit 9Bit 9Bit
Minimum illuminator 0.1LUX/F1.2 0.1LUX/F1.2 0.1LUX/F1.2 0.01LUX/F1.2 0.01LUX/F1.2
S/N Ratio >48dB >58dB
AES 1/50-1/60,000sec(PAL),1/60-1/60,000sec(NTSC)
WDR — D-WDR D-WDR D-WDR D-WDR
DNR — 3D-DNR 3D-DNR 3D-DNR 3D-DNR
OSD — OSD OSD OSD OSD
White Balance ATW ATW/Manual/Auto
AGC AUTO Auto/Manual/Off
BLC ON ON/OFF
Gamma Adjusting 0.45
synchronization System Internal Synchronization
Video Output 1.0Vp-p,75Ω
IR 5*24
IR Distance 20 Meter
LENS 3.6mm     (2.8mm 6mm optional)
Voltage DC12V (9V ~ 15V)
Operating Enviroment ~ / 10% ~ 95%RH
Demension 107×85×60mm / BOX:167×92.5×115mm
Weight 0.25kg(N.W),0.3kg(G.W)
packing 6pcs/ctn CBM: 65×40×32.5cm



















 1/3'' Sony EFFIO 700 TVL waterproof IR Camera1/3'' Sony EFFIO 700 TVL waterproof IR Camera
