Home > Auto, Motorcycle Parts & Accessories > Car Safety > Car DVR > 1080P H.264 Full Real-time CCTV DVR Recording 16CH HD SDI DVR

1080P H.264 Full Real-time CCTV DVR Recording 16CH HD SDI DVR

1080P H.264 Full Real-time CCTV DVR Recording 16CH HD SDI DVR thumbnail-1
1080P H.264 Full Real-time CCTV DVR Recording 16CH HD SDI DVR photo-1
US$ 10 - 80 MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
KAANSKY
Model Number:
KST-6616C
Contact Supplier Request Quote Chat Now
Shenzhen Kaansky Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name KAANSKY
Model Number KST-6616C

Features:

1. The latest H.264 compression.
2. User friendly Graphic interface.
3. With 4/8 CH 1080P resolution recording.
4. Remote full access via IE & client software.
5. Mobile viewing from smart phone and pad.
6. Unique files systems for security.
7. E-sata connector for fast backup, HDMI output for high definition images.
8. Projects application design, support 8 pieces SATA HDD

1080P H.264 Full Real-time CCTV DVR Recording 16CH HD SDI DVR



Model KST-4604A KST-4608B KST-4608C KST-6616C
Video Input 4 in, SDI 8 in, SDI 16 in, 4ch SDI +12ch D1, BNC
Audio Input 4 in, BNC 8 in, BNC 16 in, BNC
HDMI Ouput Support
VGA Output  Support, resolution: 1024*768, 1280*1024, 1366*768, 1440*900, 720P, 1080P
Image Display 1/4 optional 1/4/9 optional 1/4/9/16 optional
Video Standard PAL/NTSC
Loop Output NO  Support NO
CVBS Output 1 out, BNC
Audio Output 1 out, BNC
Video Compression H.264
Video Coding Resolution PAL: D1: 704*576/HD1: 704*288/CIF: 352*288/1080P: 1920*1080/720P: 1280*720 NTSC: D1: 704*240/CIF: 352*240/1080P: 1920*1080/720P: 1280*720
Record Frame Rate PAL: 100fps (4*25fps). NTSC: 120fps (4*30fps) PAL: 200fps (8*25fps). NTSC: 240fps (8*30fps) PAL: 400fps (16*25fps). NTSC: 480fps (16*30fps)
Video Frame Rate PAL: 1-25FPS. NTSC: 1-30FPS
Video Bit Rate 720P: 1536KBPS-3072KBPS, 1080P: 4608-6114KBPS; D1: 768-1536KBPS; HD1: 512-1280KBPS; CIF: 384-768KBPS; QCIF: 192-384KBPS
Audio Compression ADPCM
Record Type Always/Schedule/Alarm recording/Motion detection recording
Audio Bit Rate 8-32kbps
Dual Stream Support
Mobile Surveillance Support Android phone/ iPhone/ iPad/ Blackberry
Record Resolutioin 4CH 1080P Recording & 4ch Realtime Playback 4CH 1080P Recording & 4ch Realtime Playback 16CH 720P Recording & 16ch 720P Playback
Sync Playback 1-4ch optional 1-4ch optional 1-8ch optional
HDD Type 1 piece SATA 2 pieces SATA 8 pieces SATA 8 pieces SATA
Storage Capacity 4 TB for each Sata connector 3 TB for each Sata connector
Voice Intercom Input Support
Audio Record Mode Audio & Video recording simultaneously
Network port 1 RJ45 10M/ 100M/1000M 2 RJ45 10M/ 100M/1000M
Serial Port 1 RS-485 serial port 2 RS-485 serial port
E-SATA Port Support
USB Port 2 USB
Firmware Upgrade Mode Support USB update/Network update
Alarm In/Out 4 in, 2out 8in, 4out 16 in, 4 out
Power Supply 12V@5A ATX Power
Consumption (HDD not include) <=15W <=70W
Operating Temperature -10C--+55C
Operating Humidity 10%-90%
Case Standalone 1.1U Standalone 2.0U
Dimensioin 321mm(W)*405mm(l)*64mm(H) 435mm(W)*440mm(L)*90mm(H)
Weight (HDD not include) <=3Kg <=6Kg



1080P H.264 Full Real-time CCTV DVR Recording 16CH HD SDI DVR
