Product Details
| Place of Origin | Guangdong, China | Brand Name | Kaansky | |
| Model Number | KST-S03 | Type | Digital Camera | |
| Style | Mini Camera | Sensor | CCD | |
| Technology | Infrared | Special Features | Waterproof / Weatherproof |
Product Description
Specifications
-Mini Camera-Standard 3.6mmLens
-OEW is welcome
-CE FCC ISO9001 RoHS can be approved
SONY Color CCD 3.7mm pinhole lens CCTV Mini camera
About us:
Shenzhen KAANSKY Technology Co., Ltd. is a high-tech enterprise integrating technical consultation, product development, production and sales. With 6 years experience in manufacturing cctv camera, more than 100 skilled workers can produce 30,000 high-quality CCTV camera monthly for OEM orders. supported by the strong R&D team. Our products have honored certificates of CE, FCC, CCC, ROHS, and IP66.
Our main is "Common make Uncommon" !
OEM/ODM Service:
Our company has long term and extensive experience in OEM/ODM service; we sincerely hope to make the cooperation with any company, enterprise and individual with OEM/ODM service. We can assist you from the sample to the final product as follow.
Features:
Standard 3.6mmLens
Easy installation with bracket
| Model | KST-S03-P442 | KST-S03-S342 | KST-S03-N604 | KST-S03-E520 | KST-S03-E650 |
| Image Sensor | 1/4" COLOR SHARP CCD | 1/3" COLOR Super HAD CCD | 1/3" COLOR SONY Super HADCCD | 1/3" COLOR SONY EFFIO | 1/3" COLOR SONY EFFIO |
| TV System | PAL/NTSC | ||||
| Image Resolution | PAL:500(H)×582(V), NTSC:510(H)×492(V) | PAL:500(H)×582(V), NTSC:510(H)×492(V) | PAL:752(H)×582(V), NTSC:768(H)×494(V) | PAL:752(H)×582(V), NTSC:768(H)×494(V) | PAL:976(H)×582(V), NTSC:976(H)×494(V) |
| Horizontal Resolution | 420TVL | 420TVL | 600TVL | 520TVL | 650TVL |
| Digital to Analog | 9Bit | 10Bit | 9Bit | 9Bit | |
| Minimum illuminator | 0.1LUX/F1.2 | 0.1LUX/F1.2 | 0.1LUX/F1.2 | 0.01LUX/F1.2 | 0.01LUX/F1.2 |
| S/N Ratio | >48dB | >58dB | |||
| AES | 1/50-1/60,000sec(PAL),1/60-1/60,000sec(NTSC) | ||||
| WDR | — | — | D-WDR | D-WDR | D-WDR |
| DNR | — | — | 3D-DNR | 3D-DNR | 3D-DNR |
| OSD | — | — | OSD | OSD | OSD |
| White Balance | ATW | ATW/Manual/Auto | |||
| AGC | AUTO | Auto/Manual/Off | |||
| BLC | ON | ON/OFF | |||
| Gamma Adjusting | 0.45 | ||||
| synchronization System | Internal Synchronization | ||||
| Video Output | 1.0Vp-p,75Ω | ||||
| IR | — | ||||
| IR Distance | — | ||||
| LENS | 3.6mm Lens | ||||
| Voltage | DC12V (9V ~ 15V) | ||||
| Operating Enviroment | ~ / 10% ~ 95%RH | ||||
| Demension | 55x55x81mm / BOX:115x115x90mm | ||||
| Weight | 0.25kg | ||||
| packing | 52pcs/ctn CBM: 60×40×32.5cm | ||||
Factory pictures :
Certifications :
The packing :
More informations you will interested :
Q:How can we get samples from you?
A:Clients select the interested items, including product name and quantity
B: We need your address for checking air shipping cost.
C: We make Sample PI for you
D: You make the transfer
E: Samples will be sent out once we get the transfer, and we'll provide the UPS Tracking number.
Q: How many days do we need to wait for the samples?
A: If for our brand products, we can ship them out with 5 working days. If for OEM samples, 1 week is required to prepare samples.
Q: What’s the MOQ?
A: Depends on what products that you need, if go with our brands, the MOQ is 100.
B: As for OEM, it depends on the carton,the label,the logo. the MOQ is 5,00pcs.
Q: Can we be your distributor? What’s the requirement of being distributors?
A: Welcome to being distributor, we’d like to invite partners to be our distributors and enjoy our brand reputation. We have a small request, pls send us email, we’ll call you or email you right away.
Q: What’s the delivery date?
A: If for our brand products, we’ll ship the goods within 3-5 working days. If for OEM products, it’s about 10-15days, depends on the quality packaging.
Q: What’s your payment terms?
A: For those lower than USD15,000/order, need to pay 100% once confirming the order. For above amount, 40% deposit, and the balance before delivery date. And we accept LC also.
Q: How can we pay you?
A: We accept Western Union, TT and LC, you can select which type is most suitable for you.
