10x zoom Camera PTZ camera Outdoor IR MINI PTZ Camera 6*HLED 50M

Specifications

1.CCTV Camera Professional Manufacturer
2.Products certificate: CE, FCC, RoHS etc
3.Delivery:3-5working days after payment

Features:

Name: MSD202 High speed dome camera
Model: KST-MSD202
Features:
With Chinese and English Menu,Image, OSD Function(optional)
Adopt 0.1 Degree Step Dotor , NO picture ,Shaking Shen Sorking in LOW speed,
Built-in Kinds of Integrated Intelligent cameras
255 Preset Positions, Support Scenario Name Setting,Support privacy hidden function
8 pcs Cruising Tracking,(Max 16 Preset Positions in Each Cruising Tracking )

Pan Speed 0.01°-240°/S





 360° continuous running, Vertical range: 0°~90°, Auto flip: 180°.
 Rotation speed: pan: 0.05°/S-300°/S, Tilt: 0.1°/S-200°/S.
 Presets:256 presets, 6 preset patrol path, 4 groups pattern scan,
 Privacy zones: 8 zones;
 System has power-off protection, PTZ will restore to the state before power off
 PTZ restarts automatically by calling preset 91, which without power-off
 PTZ can work automatically when it’s free, such as call presets, running pattern scanning and cruise scanning, etc.
 4ch input, 1ch alarm output.
Built-in strong electrical and lightning protection.
Built-in strong electrical and lightning protection.
RS-485 Long distance control
200mm*200mm*200mm/1.7kgs



Power		DC12V/4A, 50Hz
Horizontal Resolution		700TVL
Lens		10x optional
IR		6*HLED
IR Distance		60M
Synchronization		Internal
Video output		1.0Vp-p
Focal & Iris		Auto
Auto scanning		2
Pan Rotation Range		360° Continuously
Pan Speed		Middle speed:0.1°/S-120°/S
		High speed:0.05°/S-240°/S
Tilt Rotation Range		vertical 90°/180°
Tilt Speed (Vertical)		Middle speed:0.5°/S-50°/S
		High speed:0.1°/S-200°/S
Preset		256
Control method		RS485
Baud rate		2400/4800/9600/19200bps
Operating Enviroment		outdoor use:-40- +55°C
Protection Grade		IP66
