Help Center900TVL Indor IR Mini PTZ Camera 4" Small Size Speed Dome Camera 36PCs*F6 30M IR Distance
Related Products
-
700TVL Indoor IR Micro Ptz Camera 4" Small Size Speed Dome Camera 10x ZoomUS$ 10 - 150MOQ: 1 Piece -
Outdoor IP66 10x Mini High Speed Dome Camera With OSD Function OptionalUS$ 10 - 150MOQ: 1 Piece
-
900TVL Micro Ptz Camera 4" Small Size Speed Dome Camera 10x ZoomUS$ 10 - 150MOQ: 1 Piece
-
30x Zoom Focus 700TVL PTZ RS485 Protocal High Speed Dome CameraUS$ 10 - 150MOQ: 1 Piece
-
Hot Sell 2014 New Products Intelligent ir High Speed Dome CameraUS$ 10 - 150MOQ: 1 Piece
Features:
Name: MSD201 High speed dome camera
Model: KST-MSD201
Features:
With Chinese and English Menu,Image, OSD Function(optional)
Adopt 0.1 Degree Step Dotor , NO picture ,Shaking Shen Sorking in LOW speed,
Built-in Kinds of Integrated Intelligent cameras
255 Preset Positions, Support Scenario Name Setting,Support privacy hidden function
8 pcs Cruising Tracking,(Max 16 Preset Positions in Each Cruising Tracking )
Pan Speed 0.01°-240°/S
360° continuous running, Vertical range: 0°~90°, Auto flip: 180°.
Rotation speed: pan: 0.05°/S-300°/S, Tilt: 0.1°/S-200°/S.
Presets:256 presets, 6 preset patrol path, 4 groups pattern scan,
Privacy zones: 8 zones;
System has power-off protection, PTZ will restore to the state before power off
PTZ restarts automatically by calling preset 91, which without power-off
PTZ can work automatically when it’s free, such as call presets, running pattern scanning and cruise scanning, etc.
4ch input, 1ch alarm output.
Built-in strong electrical and lightning protection.
Built-in strong electrical and lightning protection.
RS-485 Long distance control
200mm*200mm*200mm/1.7kgs
| Model | KST-MSD201 | |
| Effective Pixels | 976(H) ×494(V) | |
| Optical Zoom | 10X,f=3.8 to 38mm(F1.8) | |
| Resolution Ratio | ≥650tvl | |
| Vedio Output | 1.0vp-p | |
| S/N Ratio | ≥50dB(AGC Off,Weight ON) | |
| IR | 30pcsx5mm | |
| Minimum Illumination | Color:0.1Lux/F1.8(50 IRE) B/W:0.01Lux/F1.8(50 IRE) | |
| BLC | Low,Middle,High | |
| Camera ID | 255 | |
| Day & Night Conversion | Auto,Color,B/W(ICR) | |
| AGC | Low,High,OFF | |
| White Balance | ATW:indoor(3.000°K~6.500°K),outdoor (1.800°K~10.500°K)/AWB/Manual | |
| Electronic Shutter | Auto/Manual(x128~1/60sec~1/120,000sec) | |
| O.S.D Menu | Built-in Menu in English | |
| HLC | ON/OFF | |
| Focus | Auto/Manual | |
| Zoom Speed | 1.65sec:from near focus to far focus | |
| lens Initialization | Built-in | |
| Privacy Cover | 8 areas in total | |
| Mirror Image | ON/OFF | |
