Newest! Dahua HD CVI DVR 8ch 720P HD-CVI DVR for Recording HD Cvi Camera

Newest! Dahua HD CVI DVR 8ch 720P HD-CVI DVR for Recording HD Cvi Camera thumbnail-1
Newest! Dahua HD CVI DVR 8ch 720P HD-CVI DVR for Recording HD Cvi Camera photo-1
Negotiable MOQ: 50 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
KAANSKY
Model Number:
KST-7108
Contact Supplier Request Quote Chat Now
Shenzhen Kaansky Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
ShenZhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name KAANSKY
Model Number KST-7108

Specifications

fessional manufacturer in Shenzhen.
2.OEM,ODM
3.CE,FCC,CCC,RoHS
4Focus on IP camera,HD-SDI camera,high speed dome camera

Features:

1.The latest H.264 compression

2.User friendly Graphic interface

3.with 4/8CH 720P resolution recording

4.Remote full access via IE&client software

5.Mobile viewing from smart phone and pad

6.Unique files system for security

7.E-sata connector for fast backup,HDMI output for high definition images

Model KST-7104 KST-7108 KST-6216
Operating System Embedded LINUX
Video Input 4 channel, BNC 8channel, BNC 16 channel, BNC
Standard NTSC(525Line, 60f/s), PAL(625Line, 50f/s)
Audio Input 4 channel, BNC   Output:1channel,BNC
Video Interface 1 HDMI, 1 VGA ,1 BNC
Resolution 1920×1080, 1280×1024, 1280×720, 1024×768
OSD Camera title, Time, Video loss, Camera lock, Motion detection, Recording
Video/Audio Compression H.264 / G.711
Record Resolution 720P(1280×720/1280×600)/960H(960×576/960×480)/D1/4CIF(704×576/704×480) / CIF(352×288/352×240) / QCIF(176×144/176×120)
Record Rate Main stream 720P/960H/D1/HD1/2CIF/CIF(1~25/30fps)
Extra stream CIF/QCIF(1~25/30fps)
Recording Mode Manual, Schedule(Regular(Continuous), MD, Alarm), Stop
Recording Interval 1~120 min (default: 60 min), Pre-record: 1~30 sec, Post-record: 10~300 sec
Video detection Motion Detection, MD Zones: 396(22×18), Video Loss & Camera Blank
Alarm Input 4 channel 8channel 16channel
Trigger Events Recording, PTZ, Tour, Alarm, Video Push, Email, FTP, Spot, Buzzer & Screen tips
Sync Playback 1/4 1/4/8 1/4/8/16
Search Mode Time/Date, Alarm, MD & Exact search (accurate to second), Smart search
Backup Mode USB Device / Network
Ethernet RJ-45 port (10/100M/1000M)
Network Functions HTTP, IPv4/IPv6, TCP/IP, UPNP, RTSP, UDP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP, IP Filter, Alarm Server
Max.User access 128users
Smart Phone iPhone, iPad, Android, Windows Phone
Internal HDD 1 SATA port,up to 4TB 2SATA port,up to 4TB
USB interface 2ports(1 rear)USB2.0
RS485 1port,for PTZ control
Power Supply AC 100~240 V, 50/60 Hz
Working Environment -10 ~+55°C / 10~90%RH / 86~106kpa

 Newest! dahua HD CVI DVR 8ch 720P HD-CVI DVR for recording HD cvi cameraNewest! dahua HD CVI DVR 8ch 720P HD-CVI DVR for recording HD cvi cameraNewest! dahua HD CVI DVR 8ch 720P HD-CVI DVR for recording HD cvi cameraNewest! dahua HD CVI DVR 8ch 720P HD-CVI DVR for recording HD cvi cameraNewest! dahua HD CVI DVR 8ch 720P HD-CVI DVR for recording HD cvi camera
