Home > Security & Protection > Surveillance, Control & Protection > CCTV Camera > 700tvl Sony Nextchip 2090 Infrared Security Waterproof Camera

700tvl Sony Nextchip 2090 Infrared Security Waterproof Camera

Name: 700tvl Sony Nextchip 2090 Infrared Security Waterproof Camera
Brand: KAANSKY
SKU: 122029931

US$ 10 - 80 MOQ: 1 Piece

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

KAANSKY

Model Number:

KST-D13C

Shenzhen Kaansky Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name KAANSKY

Model Number KST-D13C

Type Analog Camera

Style Dome Camera

Sensor CCD

Technology Infrared

Special Features Waterproof / Weatherproof

Features:

760H/960H analog camera (box, dome, module, etc)

Horizontal resolution 700TVL

On-chip AFE

Enchanced Smart IR, 2D-NR

D-WDR

De-moire

Motion detection (48*15)

Dead pixel correction (white & black)

High light compensation

Lens shading correction

Parking line guide display

Privacy mask (8 zones)

OSD: English/Chinese<s>/Chinese/Spanish/Russia/Japanese/ Portuguese/German/French

RS-485(Pelco-D/P, Nextchip); Coaxial Comm.(Pelco-c)4

Model	KST-FD06-C90	KST-FD06-N70	KST-FD06-E65	KST-FD06-EV800
Image Sensor	1/3" COLOR Super HAD DIS	1/3" COLOR NVP SONY CCD	1/3" COLOR SONY EFFIO	1/3" COLOR SONY EFFIO-V
TV System	PAL/NTSC
Image Resolution	PAL:976(H)×582(V), NTSC:976(H)×494(V)	PAL:976(H)×582(V), NTSC:976(H)×494(V)	PAL:976(H)×582(V), NTSC:976(H)×494(V)	PAL:976(H)×582(V), NTSC:976(H)×494(V)
Horizontal Resolution	900TVL	700 TVL	700 TVL	800TVL
CCD+DSP	DIS1099 DIS138+FH8510+IR CUT	811ccd+NVP2090 2341ccd+NVP2090	811ccd+EFFIO4151 673ccd+EFFIO4151	663ccd+EFFIO4141 ISRAEL K700
Digital to Analog	9Bit
Minimum illuminator	0.1LUX/F1.2
S/N Ratio	≥48dB	≥58dB
AES	1/50-1/100,000sec(PAL),1/60-1/100,000sec(NTSC)
WDR	D-WDR	D-WDR	D-WDR	SUPPER WDR
DNR	2D-DNR	2D-DNR	3D-DNR	3D-DNR
OSD	OSD	OSD	OSD	OSD
White Balance	ATW/Manual/Auto
AGC	Auto/Manual/Off
BLC	ON/OFF
Gamma Adjusting	0.45
synchronization System	Internal Synchronization
Video Output	1.0Vp-p,75Ω
IR	24PCs F5mm
IR Distance	30-40 Meter
LENS	2.8-12mm
Voltage	DC12V (9V ~ 15V)
Operating Enviroment	~ / 10% ~ 95%RH
Size	Body: 281x98x139mm;
Weight	1.5kgs/1.25kgs
packing	Color box: 155x155x106mm;24pcs per caton; Dimension: 650x400x325mm, appro. 0.0845cbm;
