Specifications
25 Ton Rotator Tow Truck (long head cabin type)in safety, comfort, easy maintenance, fuel economy and other aspects
25 Ton Rotator Tow Truck (long head cabin type)
Specification
Model |
ST5302TQZCZ |
|
|
Chassis |
Model |
SINOTRUK ZZ5439N506CD1 |
Wheel Base(mm) |
1950+5025+1350 |
|
Engine Model/Power(kw) |
D10.34-40/249 |
|
|
Under-lift |
Max. towing mass(kg) |
32000 |
Rated lifting weight(kg) |
6000-16000 |
|
Max. effective length(mm) |
3760 |
|
Extension Stroke(mm) |
2090 |
|
|
Boom |
Max. lifting weight(kg) |
25000 |
Max. lifting height(mm) |
11500 |
|
Rotation Angle(°) |
360°continious |
|
Rated pulling force of winch |
150KN×2 |
|
|
Outrigger |
Front outrigger transverse span(mm) |
5110 |
Rear outrigger transverse span(mm) |
4225 |
|
Front and rear outrigger transverse span(mm) |
6115 |
|
Technical characteristics
1.We Adopt SINOTRUK WEILUO chassis, with 25DZ20T coat, it is the first tip rotation wrecker. With respect to the flat cab chassis, in safety, comfort, easy maintenance, fuel economy and other aspects have a distinct advantage.
2.Tops main, jib rotary device, boom, corbel, legs and toolbox consists of several parts, such as the sub-frame, the important components of high quality high-strength steel.
3.Hydraulic system uses two filtering technology to ensure that the hydraulic system clean and all have security lock cylinder valve, increase security strength. All job actions are hydraulically operated, by manipulating the joystick on both sides, to achieve wrecker lift, lift, twist pulling, lifting, turning and other functions. Optional wired or wireless control manipulation, dangerous scenes for remote operation.
4.It is equipped with height, width five sizes fork lifts, seat height of two forks that can handle all types of vehicle failure in different ways. The rear brake is equipped with pneumatic quick connector, which enables simultaneous brake towed vehicle.
Shandong Lufeng Special-Purpose Vehicle Co.,Ltdis a group company with over 40 years history on automobile manufacturing. Our company main products consist of LUFENG brand semi-trailer, dump truck, concrete mixer truck, tow truck and other special vehicles. The annual output capacity has reached 10000 units. Our company develop ourselves in providing special vehicles for global market. Lufeng group has two subsidiaries: Tai’an Tongyuan Machinery Co.,Ltd & Shanghai Luqing International Trade Co.,Ltd.
Tai’an Tongyuan Machinery Co.,Ltd is a professional manufacturer of high quality tow trucks, and tow truck capacity is from 3 ton to 60 ton.
Shanghai Luqing International Trade Co.,Ltd founded in Shanghai Free Trade Zone by Lufeng Group. We engaged in import and export of vehicles, equipments and machineries. With particular location and policies advantages of Shanghai free trade zone, the products have been exporting to majority countries of the world.
Workshop
Certification
Selling Network
Loading Port: QINGDAO,TIANJIN,SHANGHAI or other ports at China
Payment term: by T/T,30% advanced payment, and balance before shipment by T/T ;
by L/C,50% deposit by T/T, and 50% by irrevocable L/C at sight
Delivery time: The goods shall be prepared for shipment within seven days after receiving balance payment
Min. order quanlity: 1 set
Supply ability: 200 sets/month
