chain saw file guide

Specifications

1.Engine displacement:52cc
2.Rated output power:2.2kw
3.Guide bar length:18'' 20'' 22''
4.High Performance
5.CE Approved

• Displacement:  52CC
• Maximum output: 2.2kW/3.0HP
• Bore x stroke: 45 x 31mm
• Chain oil supply system: auto
• Fuel tank capacity: 530mL/15.6oz
• Chain oil tank capacity: 270mL/8.0oz
• Guide bar: 18, 20, 22 inches/45, 50, 55cm
• Chain saw (pitc x gauge): Oreng 75LP 3/8 x 0.063(9.53 x 1.60) inches (mm),
• 21bp 0.325 x 0.050(8.26 x 1.47) inches (mm)
• Teeth of sprocket: 7
• Fuel mixing rate: 90#gasoline: 2-cycle special oil (capacity rate), up to 20 hours use 20:1, after use 25:1
• External size: (L) 395 x (W) 240 x (H) 235mm
• Dry weight (without bar and chain): 5.0kg/11ibs
