Specifications
315mm Drainage Pipe Fusion Machine1. welding range : 90mm~ 315mm
2. Single-Layer insert
3, for Thin HDPE pipes
315mm Drainage Pipe Fusion Machine
PE Pipe Welding Machine, But Fusion Welding Machine, Hot-melt Welding Machine, Manual fitting welding machine, Elbow Fitting weding machine, Workshop welding machine for elbow prefabrication, workshop fitting machine for elbow fittings. RST315 Drainage System Fusion Machine , Portable heating fusing machine.
Application:
Suitable for welding of plastic pipes and fittings made of PE,PP,PVDF and can be operated in any complex
working condition.
Features:
1. Used to install drainage system in building , Specially designed clamps according to features
in structure and dimension of fitting in drainage system
2. Removable PTFE coated heating plate with high accurate temperature control system
3. Electrical planing tool with safety limit switch enables it to be started only when it is lock in
operation position
4. Pivoting planing tool and heating plate brings convenience to placing and removing
5. It consists of a machine with a pressure regulating device. A pair of clamps, two lateral
supports, clamps adapters , lateral supports adapters, an electrically controlled milling cutter
for levelling the end of the pipe or fitting with a safety microswitch, an extractable heating plate
with automatic device to control the temperature.
Welding ranges |
160mm-180mm-200mm-225mm-250mm-280mm-315mm |
Ranges of application |
PE,PP and PVDF |
Working voltage |
~220V ±10%,50Hz |
Environment temperature |
-10° ~ 45° |
Total power |
planing tool:1.1 kW, heating plate: 3.1 kW |
components |
basic frame, heating plate, planing tool,electric box |
heating plate characteristics |
PTFE coated heating plate, adjustable knob for temperature control, difference in heating plate surface temperature ≤±7°. |
Other device |
Electronic count-down timers for heating and cooling time. |
315mm Drainage Pipe Fusion Machine :
