RDH1200 PE Pipe Butt Welding Machine

Specifications

RDH1200 PE Pipe butt welding machine:

PE Pipe Welding Machine,  But Fusion Welding Machine, Hot-melt Welding Machine, Hydraulic butt fusion welding machine. Hydraulic butt welding machine, HDPE butt fusion machine. Welding machine. Butt fusion Equipment

Application:

Suitable for welding of plastic pipes and fittings made of PE,PP,PVDF and can be operated in any complex

working condition.

Features:

*Suitable for butt welding of plastic pipes and/or fittings made of PE,PP,PVDF and PPR in worksite or workshop.
*Consists of basic frame, hydraulic unit, planing tool, separate heating plate, support for planing tool&heating plate.
*Removable PTFE coated heating plate with high accurate temperature control system.
*Electric planning tool with safety limit switch enables to start it only when it is locked in operation position.
*Made of lightweight and high strength material. Specially designed with a clamp opening angle of 45 degrees.
*Low starting pressure and high reliable seal structure.
*Changeable welding position brings more convenience while welding various fittings.
*Separate two-channel timer records times in soaking and cooling phases.
*High-accurate and shockproof pressure meter indicates clearer readings.
*Labor saving and high efficient crane is available to lift planing tool and heating plate.

RDH1200 PE Pipe butt welding machine:

Model RDH1200

Name:PE Pipe butt welding machine

Weldingranges 630mm—710mm—800mm—900mm—1000mm—1200mm

Ranges of application PE,PP and PVDF

Heating Plate Max. Temp. 270°C

Temp. Deviation in surface ±7°

Working voltage ~380V ±10%,50Hz

Environment temperature -10° ~ 45°

Heating Plate Power 29.2 KW

Planing Tool Power 3 KW

Hydraulic unit Power 3 KW

Eletric crane Power: 1KW

Total Power 36.2KW

Net Weight 3596KGS

Basic Frame Dimension 2900×2100×2030

Support Dimension 1700×1200×2200

Hydraulic unit Dimension 860×510×660

Hoist Dimension:3100×600×450

Electric Crane Dimension: 530×360×400
