Specifications
hdpe pipe joint machine1. welding range : 400mm~ 630mm
2.application: water,gas,irrigation
3.CE and ISO9001
hdpe pipe joint machine
PE Pipe Welding Machine, But Fusion Welding Machine, Hot-melt Welding Machine, Hydraulic butt fusion welding machine. Hydraulic butt welding machine, HDPE butt fusion machine. Welding machine. Butt fusion Equipment
Application:
Suitable for welding of plastic pipes and fittings made of PE,PP,PVDF and can be operated in any
complex working condition.
Features:
1. The machine body is equipped with four main clamps with the third clamp axially moved and adjusted.
2. Removable PTFE coated heating plate with separate temperature control system.
3. Electric milling cutter with reversible double cutting edge blades.
4. Hydraulic unit provides welding machine with compressing power.
5. Be made of lightweight and high strength material; simple structure and easy to operate.
6. Low starting pressure ensures reliable welding quality of small pipes.
7. Separate two-channel timer shows time in soaking and cooling phases.
8. High-accurate and shockproof pressure meter indicates clearer readings.
Techinical Specification:
1. Welding range: 400 — 630 mm in diameter
2. Heater maximum temperature : 2 7 0°C
3. Trimmer power: 1500W 380V 50Hz
4. Heater power: 9200W 380V 50Hz
5. Hydraulic unit power: 1500W (0-63bar) 380V 50Hz
6. Temp. deviation in surface: 170-250°C ± 7 °C
Optional Accessories:
Stub End Device:
electric Crane and Hoist
Bead Remover:
