Specifications
butt fusion machine for HDPE pipes and fitings1. welding range : 400mm~ 630mm
2.application: water,gas,irrigation,drainage
RDH630 butt fusion machine for HDPE pipes and fitings
PE Pipe Welding Machine, But Fusion Welding Machine, Hot-melt Welding Machine, Hydraulic butt fusion welding machine. Hydraulic butt welding machine, HDPE butt fusion machine. Welding machine. Butt fusion Equipment
Application:
Suitable for welding of plastic pipes and fittings made of PE,PP,PVDF and can be operated in any complex working condition.
Features:
1. The machine body is equipped with four main clamps with the third clamp axially moved
and adjusted.
2. Removable PTFE coated heating plate with separate temperature control system.
3. Electric milling cutter with reversible double cutting edge blades.
4. Hydraulic unit provides welding machine with compressing power.
5. Be made of lightweight and high strength material; simple structure and easy to operate.
6. Low starting pressure ensures reliable welding quality of small pipes.
7. Separate two-channel timer shows time in soaking and cooling phases.
8. High-accurate and shockproof pressure meter indicates clearer readings.
Technical Specification:
u Welding ranges: plastic pipes: 400mm-630mm
(400mm—450mm—500mm—560mm-630mm)
u Extended to 400mm-630mm
u Ranges of application: PE,PP and PVDF
u Working voltage: ~380V ±10%,50Hz
u Total power: 12.2 kW, including: planing tool:1.5 kW, heating plate:9.2 kW , hydraulic unit
motor: 1.5kW
u PTFE coated heating plate, adjustable knob for temperature control, difference in heating plate surface temperature ≤±7°.
u Environment temperature: -10° ~ 45°
u Electronic count-down timers for heating and cooling time.
u Whole machine consists of basic frame, heating plate, planing tool, hydraulic unit and support
(for planing tool & heating plate)
Company Profile:
Wuxi Yuda Plastic Pipe Welding Machinery Factory is an enterprise devoted to plastic pipe welding technology and
research, design, manufacture, sales, training and maintenance of plastic pipe welding equipment, providing the customers
with full and best service.
Our factory has a senior technical team engaged in plastic pipe welding technology research and design of welding
equipment. The guideline of our enterprise is that customers need is our pursuit, the product quality is the life of the
enterprise, enterprise's aim is to be world-famous.
Our product category falls into RGH series multi-angle fitting welding machine, DQJ series multi-angle cutting machine, RDH series Hydraulic butt fusion welding machine, Controlling methods include hydraulically-controlled and automatically( numerically)-controlled. With the great efforts of all the staff, all types of machines will be gradually be becoming perfect.
At present, the following models are available: RDHS160 and RDHS200 manual butt fusion machine, RDH160~RDH2000
Hydraulic butt fusion machine, RGH315~RGH1200 multi-angle fitting welding machine, DQJ315~DQJ1200 multi-angle cutting machine, RDH-JL160~RDH-JL1600 Automatic butt fusion machine (with data logger and printer function). Full-automatically & numerically controlled welding machine, which is called RDH-AUTO series; numerically-controlled
multi-angle fitting welding machine, which is called RGH-AUTO series and numerically-controlled multi-angle cutting machine, which is called DQJ-AUTO series will be brought to the market soon
