Welding Machine Hdpe Pipe 450mm

Welding Machine Hdpe Pipe 450mm photo-1
US$ 4,300 - 4,800 MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Jiangsu, China
Brand Name:
YUDA
Model Number:
RDH450
Payment & Shipping
Payment Methods:
Port of Shipment:
SHANGHAI
Delivery Detail:
Delivery time depends on order quantity.
Place of Origin Jiangsu, China
Brand Name YUDA
Model Number RDH450
Power 8.2KW
Dimensions 2.66CBM
Usage PE,PP,HDPE,PPR butt fusion

Specifications

Welding Machine hdpe pipe 450mm
1. best price, best service
2. CE and ISO9001
3. Semi-automatic welding

 Welding Machine hdpe pipe 450mm



PE Pipe Welding Machine,  But Fusion Welding Machine, Hot-melt Welding Machine, Hydraulic butt fusion welding machine. Hydraulic butt welding machine, HDPE butt fusion machine. Butt Fusion Jointing Machine, PE Welder, Poly Pipe Welder, Butt fusion Equipment





Application:



Suitable for welding of plastic pipes and fittings made of PE,PP,PVDF and can be operated in any complexworking condition.





Features:



1. The machine body is equipped with four main clamps with the third clamp axially moved and adjusted.

2. Removable PTFE coated heating plate with separate temperature control system.

3. Electric milling cutter with reversible double cutting edge blades.



4. Hydraulic unit provides welding machine with compressing power.



5. Be made of lightweight and high strength material; simple structure and easy to operate.

6. Low starting pressure ensures reliable welding quality of small pipes.



7. Separate two-channel timer shows time in soaking and cooling phases.



8. High-accurate and shockproof pressure meter indicates clearer readings.









Model: RDH 450



Name: Welding Machine hdpe pipe







Pipe Size : 280.315.355 400.450mm







Heating Pltae Max. Temperature: 270°C







Temperature Variation in surface(170°~250°): <±7°C







Pressure adjustable range: 0~6.3Mpa







Working Voltage: 380V, 50HZ  ( 220V, 60HZ/50HZ , three -phase avaiable)







Heating plate power: 5.2KW







Trimmer Power: 1.5KW







Hydarulic Power:1.5KW







Total power:  8.2KW











 Welding Machine hdpe pipe 450mmWelding Machine hdpe pipe 450mmWelding Machine hdpe pipe 450mmWelding Machine hdpe pipe 450mm
