Ultrasonic nozzle cleaner machine for Seiko / xaar

Ultrasonic nozzle cleaner machine

3.Form description about  Parameter Guideline

1.The outdoor computer photo jet machine is used solvent ink which is easy to volatility and dry

rapidly, it is apt to cause the stopping up of the shower nozzle.
2. After the shower nozzle block, the permanent damage of shower nozzle often happen due to

 improperly to wash it,thus the srapping rate of shower nozzle blocking is extremely high, it raised

the cost of manufacture greatly .
3. We succeed in developing and use vibration of shower nozzle washing machine which computer

procedure to control the piezocrystal. It helps photo jet company which is using  shoer nozzle to

solve the technological problem of not damage ,wash and maintain shower nozzel.

4. Custom field

Print Head Cleaner is suitable for many kinds of out door print heads, such as XAAR, SEIKO, SPECTRA, KONIKA, EPSON etc.

Like the following:

Seiko512 / 1020/ 1024 etc

Konika 512 etc

XAAR

5. Operation

Step1 :Open the bottom lid of the machine and the lid of cleaning fluid tank

Step2:Pour cleaning fluid into the cleaning fluid tank.. The minimum should be over the water outlet port of the tank

Step3:Cover the cleaning fluid tank lid .and then the bottom lid of the machine

Step4 :Open the top lid and put onnozzle holder

Step5:To connect the inlet of print head to the flushing pipe

Step6 :To insert the print head into nozzle holder

Step7 :The inserted print head

Step8 :Pour cleaning fluid into the cleaning tank ,to close to the water outlet port

Step9:  Press the red bottom to start theultrasonic cleaning

Step10:  Press the nozzle holder by hand ,so that the nozzle can be immersed in cleaning fluid.

Step11:  Release the nozzle holder after ultrasonic cleaning about 3 min. Then press the corresponding green buttom to rinse the print head

Step12:  Repeated cleaning for several times.and Cleaning the print head again after changing the cleaning fluid . Until the cleaning fluid which jet from the nozzle is soigne and clean. Then re-install it on the printer after cleaning up the print head

we will pack the operation with the  machine .
