Specifications
1 speed:1800sets/h2 power:1500w
3 electric voltage:AC220v 50hz/60hz
4 grommet:10.5 & 13.5mm
5 MOQ: 1set
Automatic punching machine used 10.5mm and 13.5mm eyelet
1 quality good and best price
2 grommet type:10.5mm & 13.5mm
3 speed:1800sets/h
4 power:1500w
5 spare part:foot switch
6 electric voltage:AC220v 50hz/60hz
Nowadays people still manually rivet the grommet of large poster cloth. This operation has many
disadvantages:
1. unsolid joint between grommets and cloth;
2. 2. more punctures and easy cut ropes off;
3. 3. iron sheeting is easily rusted.
Meanwhile, manually punching is slow, laborious, unefficient and low quality.
Brightness automatic grommet machine is designed for solving the above problems. It can
quickly move and punch a long the cloth edge. The speed is about 1800pcs grommets per hour.
The grommets are solid, no punctures and nice. The sheeting is corrosion prevention since it
adopts engineering plastic design. It is indispensable equipment for inkjet plotting industry
because of labor saving, efficiency and good quality.
Function introduction
Brightness automatic grommet machine is controlled by microcomputer. It has ligh efficiency
and saves labor. There are four wheels under the machine so it is very convenient to move. It
also can be fixed on worktable after take off the wheels. Different types of machines can be
offered according to different power supply and voltage in different countries and areas.
There are two groups of dictate button with same functions: one is on the handle; the other is
on the shell of microcomputer. Every group is composed of red button, yellow button and green
button. Green button is for sending grommets, red button is for operating, while yellow one is
resetting. The laser light will turn on when power is on, two hoppers will operate and send to
the feed canal. It will automatically stop sending until the canal is full.
This machine is environmental protection and energy saving .It adopts electromagnetic force
directly punching and finish the task. It only uses electricity in 1% second per punching. The
average consumption of electricity is less than 3 watt during wait for another order. While
ordinary punching press needs at least several hundreds watt to keep operate.
semi-auto grommet machine
steel and iron single grommet machine
Muti direction single grommet machine
