China Small Wheel Farming Chery Tractor

China Small Wheel Farming Chery Tractor thumbnail-1
China Small Wheel Farming Chery Tractor thumbnail-2
China Small Wheel Farming Chery Tractor thumbnail-3
China Small Wheel Farming Chery Tractor thumbnail-4
China Small Wheel Farming Chery Tractor thumbnail-5
China Small Wheel Farming Chery Tractor photo-1
China Small Wheel Farming Chery Tractor photo-2
China Small Wheel Farming Chery Tractor photo-3
China Small Wheel Farming Chery Tractor photo-4
China Small Wheel Farming Chery Tractor photo-5
US$ 1,900 - 4,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Wheel Tractor
By wheel:
4WD
Contact Supplier Request Quote Chat Now
Shijiazhuang Haiju Import And Export Trade Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Wheel Tractor
By wheel 4WD
Usage Farm Tractor
Drive Type Gear Drive
Power(W) 12hp-22hp
Certificate CE
Brand Name JINMA
Model Number 121
Place of Origin Hebei, China
After-sales Service Provided Engineers available to service machinery overseas
Detailed Images

Farm Tractor 12hp 16hp,18hp,22hp,30hp,40hp,50hp,60hp.70hp,90hp,100hp,120hp,130hp



Model

30 hp

Type

4×2 Wheeled Tractor

Rated Tractive Force (kN)

6.5

Overall Dimensions(L*W*H, mm)

2500*1250*1380

Structural Mass (kg)

1070

Min. Operating Mass (kg)

1160

Wheelbase (mm)

1560

Wheel Tread (Front/Rear, mm)

980~1200/1010~1200(can be adjusted)

Min. Ground Clearance (mm)

370

Min. Turning Radius (m)

4.2

Calculating Speed (km/h)

forward

2.21/3.37/4.61/6.38/8.88/13.59/21.33/29.41

reverse

2.54/12.27

Hitch Linkage

I Type, Rear-Mounted, Three-Point Linkage

PTO Shaft Type

Rear-Mounted, Dependent, 540 rpm, Clockwise, Φ 35mm

Tire Detail(Front/Rear)



5.00-16/9.5-24

Engine



Model

JD2102

Type

Double Cylinder, Vertical, Water-cooled, 4-stroke

12-hour Rated Power (kW)

22.1

Rotate Speed (r/min)

2400

Starting Method

Electric

Bore×Stroke (mm)

100×105

Fuel Oil Consumption (g/kw*h)

≤250

Lubricating Oil Consumption (g/kw*h)

≤2.04
