Model |
LMC1290P |
Work area |
1200*900mm (Cutting work area) 1150*900 (Engraving work area) |
Work area optional |
900*600mm and other work area optional |
Laser tube power |
RECI130W(Standard), RECI150W / SF130W/SF150W(Optional) |
Engraving speed |
1000mm/s |
Cutting speed |
400mm/s |
Cutting depth |
≤1.5mm Carbon steel plate , 1.2mm Stainless steel plate ,20-30mm Acrylic,can not cut aluminum. |
Communication interface |
USB |
Work table |
Blade slat board for cutting ,Electric up and down 270mm |
Minimum forming character |
1*1mm |
Maximum scanning precision |
0.0254mm |
Positioning precision |
0.01mm |
Power supply |
220V (or 110V) +/-10% 50Hz (or 60Hz) |
Drive mode |
Step motor |
Software included |
Lasercut |
Design software |
Coreldraw(11/12/X3/X4/X5/X6), Autocad (compatible); Photoshop |
Picture format supported |
PLT, DXF, BMP, AI (direct); JPG, GIF, PGN, TIF (conversion) |
Operation system |
Windows 2000/XP/VISTA/7/8,32/64Bits |
Engrave curve surface |
Less than 1.5mm |
Cooler |
Water cooling |
Life time of laser tube |
8000-10000 hours |
|
Optional: 1.Honey comb board: used for cutting soft material, such as cloth 2. Color optional: Red, Grey, Blue, White, Orange, Black, Green, etc. 3. Japan servo system, faster speed, lower noise and higher precision. | |
|
Consumable parts (Recommended): 1.Extra 1 lens and 3 mirrors (Lens D25mm, F76.2mm. Mirror D25mm.) | |
|
Application: Sign making, Advertisement and decoration, Nameplates, Awards, Badges, Tags, Artworks making, Mould making, Architectural model, Fabric (Jean, etc.) process, Leather process, Notary seals, Rubber stamps, Souvenirs, etc. | |
|
Proper material: Metal: Carbon steel plate, Stainless steel, Coated metal sheet etc. Non-metal: Acrylic, Crystal, Bamboo, Cloth, Fabric, Denim, Fiberglass, Glass, Leather, Marble, Granite, Plastic, Paper, Rubber, Wood, MDF, etc. | |
