Help CenterGreen Laser Marking Machine 3W/5W/8W/10W Logo Marking,numbers Mini Ring Engraving Phone Case Laser Marking Machine Memory Card
Related Products
-
Desktop Metal Laser Marking MachineNegotiableMOQ: 1 -
Fiber Laser Laser Type and Air Cooling Cooling Mode Key Cutting Machines Locksmith ToolNegotiableMOQ: 1 Set
-
Co2 Laser Tube New Condition and Non Metal Material Laser Marking MachineNegotiableMOQ: 1 Unit
-
Portable Mini Fiber Laser Marking Machine 10 and 20 WatNegotiableMOQ: 1 Unit
-
China Mini Laser Marker 110x110mmNegotiableMOQ: 1
Features:
1) Use the most advanced international laser technology, and adopt special metal laser device.
2) The optical system adopts the entire seal structure, and has the laser path preview and focus indication function. More small appearance and more convenient operation.
3) No need water cooling system, and low operating noise, and the high precision temperature regulation, and supply the reliable guarantee for the long time running.
4) The integrated design with the laser device, power and work table, makes the marking efficiency high, metal marking effect perfect, and laser output mode stable.
5) Adopt special metal laser device, galvanometer scanning system etc. as critical parts, to ensure the high precision, accuracy and speed, and long term stable performance.
Application Industry:
Mark on metal surface and some non-metal material surface, especially suited to some processing and manufacturing with high precision required. Such as the electrical components, hardware, tools, integrated circuit(IC), electric appliance, mobile communication, precise machinery, glass frames, clocks and watches, decorations, automotive accessories, plastic buttons, construction material, PVC pipes and medical instrument. Recommend to apply to the textile and cloth, metal accessories, plastic accessories, ceramic, stone, and wood products.
Application Material:
Common metal and alloy (iron, copper, aluminum, magnesium, zinc, etc. all metals), rare metal and alloy (gold, silver, titanium), metal oxide (all kinds), special surface treatment materials (phosphating, aluminum annihilated, plating surface), ABS material (electric appliance shell, daily necessities), printing ink (euphotic buttons, printing products), epoxy resin (encapsulation and insulating layer of electronic components )
Technical Parameters:
Model |
DB110-G |
DB110F-G (closed) |
Marking scope |
110x110mm (Standard) 160x160mm,200x200mm,300x300mm, 400x400mm (optional) |
|
Max. laser average power |
Green laser YAG tube 3W,5W optional |
|
Min. Marking line width |
0.1mm |
|
Max. Marking depth |
0.3mm |
|
Beam quality m2 |
<6 |
|
Wavelength |
532 nm |
|
Min character size |
0.5mm |
|
Marking speed |
≤6000mm/s |
|
Repetition precision |
±0.01mm |
|
Repeat frequency |
1-100KHz |
|
Software system |
Win XP/7/8 32/64 bits + EZCAD marker system |
|
Cooling method |
Air cooled |
|
Power consumption |
200W |
|
Supply voltage |
AC220/100V±10% 50/60Hz |
|
Operating temperature |
5℃—40℃, No Condensation, No Icing |
|
Net weight(kg) |
80 |
153 |
Machine size(mm) |
840*410*710 |
920*670*1530 |
Gross weight(kg) |
110 |
223 |
Packing size(mm) |
920*710*850 |
1060*810*1750 |
