Help Center110W LED Parking Lot Shoebox Lighting Fixture
Related Products
-
75w High Efficiency Led Street Light Manufacturers LED Shoebox 300wUS$ 130 - 430MOQ: 1 Piece -
DLC ETL 110 Watt LED ShoeboxUS$ 130 - 430MOQ: 1 Piece
-
DLC ETL 75 Watt LED ShoeboxUS$ 130 - 430MOQ: 1 Piece
-
300w Led Shoebox Equal to 1000W Metal HalidUS$ 130 - 430MOQ: 1 Piece
-
300w Led Shoebox Light Led Flood Light Fixture DLC Parking Lot Light FixturesUS$ 130 - 430MOQ: 1 Piece
- ETL, cETL and DLC listed
- CREE LM80 LEDs
- Mean Well LED driver
- Available in 75W, 110W, 300W
- 120-277VAC input (347V/480V optional)
- 5000K CCT
- Typical 90 LPW
- Photocell available
- Bronze finish (black, white optional)
- 50,000 hours
- 5 years warranty
The SBAL100 parking lot LED shoebox fixture utilizes CREE LED modules and high performance LED driver, accepts 120-277VAC (200-480VAC optional), consumes 110W and produces light intensity equivalent to 300W MH fixture. The SBAL100 comes with slip fitter, TM trunnion and 6” extrusion kit mounting options, and is an ideal one-to-one replacement of conventional metal halide and high-pressure sodium lighting fixtures for parking lot applications.
Performance Summary
Input voltage: 120-277VAC (200-480VAC optional), 50/60Hz |
Input wattage: 110 watts (300W MH fixture equivalent) |
Efficacy: 85 LPW |
Lumen output: 8500 lumens |
CCT: 5000K |
CRI: 70 min. |
L70 life: 50,000 hours |
Warranty: 5 years |
|
PHYSICAL SPECIFICATION | |
Housing material |
Die-cast aluminum |
Finish |
Bronze |
MOUNTING AND WIRING | |
Mounting |
Slip fitter, TM trunnion or 6” extrusion kit |
ENVIRONMENTAL SPECIFICATION | |
Operating temp. |
-4-122°F (-20–50°C) |
Operating humidity |
20%-85% RH, non-condensing |
Storage temp. |
-22-140°F (-30–60°C) |
Ingress protection |
Suitable for dry/damp/wet locations |
ELECTRICAL SPECIFICATION | |
Input voltage |
120-277VAC, 50/60 Hz (200-480VAC optional) |
Input wattage |
110W |
Equivalent wattage |
300W MH |
Power factor |
0.90 min. |
Total harmonic distortion |
20% max. |
OPTICAL SPECIFICATION | |
Luminous flux |
8500 lm |
Efficacy |
85 lm/W |
CCT |
5000K
|
CRI |
70 min. |
Lens |
PMMA/polycarbonate |
Optics |
Type VS |
LIGHTING CONTROL | |
Dimming capacity |
N/A |
LONGEVITY AND WARRANTY | |
L70 life |
50,000 hrs. |
Warranty |
5 years |
LISTING AND CERTIFICATES | |
DLC (DesignLights Consortium) | |
ETL, cETL | |
CE, RoHS | |
Pack carton size : 57*51*28 cm
Gross Weight : 13.28 Kg / Carton
Samples shipping with FedEx, DHL.....bulk orders can be shipping by ocean
OEM
ODM
Customer private label
Slip fitter
Trunnion amount
Arm amount
1. Are you factory direct?
Yes, we have our own factory, all of our products are with competitive factory price.
2. Do you have a special price and service for wholesale?
Yes, we have the most competitive and best service to support our wholesale customers. We do supply OEM&ODM service for the wholesale, also private label is available.
3. What payment methods can I use?
You can pay by T/T, Paypal, LC.
4. How long does it take for my order to be shipped?
Generally, your order will be shipped within 7-15 working days after your payment verified. But in cas e of any hot products without raw material, it will need 15-25 days.
5. How about the warranty?
We offer 5 years warranty. All products are gone through strict test by our experienced QC before shipment.
6. How about the after sale service?
Once there is any bad defect during your usage or the new goods go bad,we will solve it for you or send you a new one for free.
