COL7201HA 1 Channel HD MI+AV H.264 / H.265 Iptv Encoder

Name: COL7201HA 1 Channel HD MI+AV H.264 / H.265 Iptv Encoder
Brand: Colable
SKU: 121888717

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Sichuan, China

Brand Name:

Colable

Model Number:

COL7201HA

Colable Electronics Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Chengdu

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Sichuan, China

Brand Name Colable

Model Number COL7201HA

COL-7201HA 1 Channel HDMI+AV H.264 / H.265 IPTV Encoder

Outline

COL-7201HA Mini H.265/H.264 IPTV encoder is most competitive cost and easy-to-use video streaming

appliance designed for professional video producers. The product support 1 channel HDMI & AV generating

dual stream of h.264/H.265 encoding output and the AAC,Mp3 audio format. From any HDMI &AV input

source such as a camera or switcher or DVD, it generates an H.264/H.265-encoded stream compliant with

RTSP, HTTP, UDP and RTMP protocols. The product can be applied to education, health care, IPTV,

conference, remote education, news interview, banking, transportation and other industries.

Features

1 channel HDMI &AV input,
Up to 720P, 1080P HD video input
Support non-video encoding
Support OSD rolling and logo inserting
System supports WINDOWS XP/VISTA/SERVER2003/SERVER2008/WIN7 32 and WIN764, LINUX
Support MP3 and AAC audio format selection
Encoding specification: BASELINE PROFILE / MAIN PROFILE/ HIGH PROFILE
Support a click to restore the default configuration
Support STB decoding
Support Main TS stream and the sub TS stream can use different network protocols for transmission (Multi-rate multi-protocol support)
Support multiple devices display at the same time on a computer
Support network directly connected, don’t need match HD collection card.
Providing RTSP/RTP/HTTP/RTMP/UDP protocol
Support H.264 Main Profile/H.264 High Profile and AAC audio.
Web control interface
Comply with CBR/VBR 16KBIT/S~12MBIT/S standard
Power less than 24W, low power watts designing.
Support Network interface full-duplex mode 1000M

Technical Specification

Video	Input	1 channel HDMI & AV input, supports HDCP
	Resolution	1920x1080/1280x720/1280x1024/1280x960/704x576
	Encoding	H.264/H.265 AVC High Profile Level 4.0(HMDI)
	Video Bitrate	0.8Mbps~12Mbps
	Bitrate mode	CBR/VBR
	GOP type	Adjustable
	Video preprocessing	De-interlacing, noise reduction, sharpening
Audio	Encoding	AAC,MP3
	Resample Rate	Adaptive output sample rate (option) 32K, 44.1K, 48K, 64K, 96K, 128K, 160K, 192K
	Sampling	24 bit
	Bitrate	64Kb/s~384Kb/s
System	RJ45	1000M Ethernet port
	Protocol	HTTP,UDP,RTSP,RTMP,ONVIF
	Configuration interface	WEB interface
	Upgrade	Software upgrades can be carried out through a network
Environment	Dimensions	(W×D×H): 146mm x 100mm x 45mm
	Net Weight	0.5KG
	Temperature	0~45℃(work), -20~80℃(Storage)
	Power Requirements	12V / DC
	Power consumption	5W
