Specifications
h 264 sdi encoder1. sdi to ip encoder
2HDMI digital interface (optional)
3.SDI (series data interfaces, optional
sdi to ip encoder mpeg4 encoding
Outline
COL5100 H.264 Encoder is a new generation broadcasting level video and audio encoding equipment from Colable Electronics, which adopts the most advanced H.264/AVC video coding arithmetic and AAC audio coding arithmetic, along with colable’s exclusive video and audio pretreatment technology, is able to realize high quality video and audio encoding and transmitting in low code rate, and provide customers superb digital video encoding solution.
Specifications
1. Video interface characteristics
Composite video signal
Video system: NTSC(525/60),PAL(625/50)(optional)
Connector: BNC
Impedance: 75W ,unbalance
Frequency :25Hz~5.75MHz
Level: 1.0Vp-p
Quantization: 12bits,subject to CCIR-601
Sampling frequency: 27MHz
S-Video/YPbPr
Connector: Mini-DIN 4
Impedance: 75W,unbalance
Y signal level: 1.0Vp-p
Y signal frequency: 25Hz~5.75MHz
C signal level: 0.285Vp-p
C signal frequency: 25Hz~2.75MHz
Quantization: 12bits(Y),12bits(C),subject to CCIR-601
Sampling frequency: 54MHz
HDMI digital interface (optional)
Video standard: Subject to HDMI v 1.3
Video standard: Subject to HDMI 1.3, S/PDIF (IEC90658) compatible
Welcome to contact our salesman directly!
